Flat Bar Sizes Slitting Manufacture Steel Flat Bar

Loading Port:Tianjin

Payment Terms:TT OR LC

Min Order Qty:30 m.t.

Supply Capability:30000 m.t./month

Product Description:



Steel Flat Bar For Many Sizes is used for manufacturing various types of springs and components, for the suspension mechanism in automobiles or the railways.With the short stress production line that can finish foundry and rolling in one process, we are able to produce dozens type of spring flat steel from 6*40mm to 20*150mm. This product is the best choice for springs and chains for car and agricultrure machine.



Product Description

Flat Bar Sizes Slitting Manufacture Steel Flat Bar

steel flat bar grade: A36, S235jr, St37-2, SS400, Q235, Q195

steel flat bar standard: ASTM, AISI, EN, DIN, JIS, GB

steel flat bar thickness:1.5mm-20mm

steel flat bar width: 10mm-1000mm

steel flat bar length: 6m, 9m, 12m or as your requirement.

steel flat bar technique: slitting hot rolled steel coil

Place of origin: Tianjin China (Mainland)

Products Advantages: 1. high quality

                                   2. high dimensional accuracy

                                   3. high utilization rate of material

                                   4. saving cost price

General specification below:



                            Steel Flat Bar

Width

(mm)

Thickness

(mm)

Length

(m)

Theoretical Weight

        (kg/m)

20

2.0

6/9/12

0.31

20

2.5

6/9/12

0.39

20

2.75

6/9/12

0.43

25

2.5

6/9/12

0.49

25

3.75

6/9/12

0.74

30

2.5

6/9/12

0.59

30

3.5

6/9/12

0.82

30

9.75

6/9/12

2.30

40

3.5

6/9/12

1.10

40

4.75

6/9/12

1.50

40

11.75

6/9/12

3.69

50

2.75

6/9/12

1.08

50

4.5

6/9/12

1.77

50

9.75

6/9/12

3.83

60

5.5

6/9/12

2.60

60

7.5

6/9/12

3.53

60

11.5

6/9/12

5.42

80

5.5

6/9/12

3.45

80

7.5

6/9/12

4.71

80

11.75

6/9/12

7.38

100

3.25

6/9/12

2.55

100

4.75

6/9/12

3.73

100

7.5

6/9/12

5.89

120

9.75

6/9/12

9.18

120

11.75

6/9/12

11.07

150

9.75

6/9/12

11.48

150

11.5

6/9/12

13.54

150

13.5

6/9/12

15.90

160

11.75

6/9/12

14.76

200

9.5

6/9/12

14.92

250

5.75

6/9/12

11.28

340

7.75

6/9/12

20.68
