Loading Port:Tianjin
Payment Terms:TT OR LC
Min Order Qty:1000 pc
Supply Capability:100000 pc/month
Fire Vermiculite Board Wholesale Fireproof Material Insulation Board for Industries Furnaces
1. material: vermiculite
2. tempreture:1100
3.The fireproof grade is A
4.Low carbon and energy-saving
Vermiculite board is a new eco-friendly material with properties of fireproofing, thermal insulating,
multi-specification, multi-purpose boards for different users around the world.
Specification details:
Process temperature | Bending strength | Density | Compression strength | Thermal conductivity |
>1100°C or 1000°C | 0.574~5.33Mpa | 400kgs/M3--900kgs/M3 | 0.690~4.90Mpa | Max.0.20W/mK at 600°CMax.0.128W/mk at 34.51°C |
Process range | The minimum thickness | The maximum thickness | The maximum width | The maximum length |
15mm | 50mm | 1220mm | 2440mm |
Characteristics
1. Eco-friendly, non-toxic and zero radioactivity, non-asbestos .
2. Excellent workability.
3. The fireproof grade is A
4.high-qulity vermiculite
5. Excellent fireproof character.
6. Heat insulation and preservation.
7. Sound insulating and absorbing.
8. Moisture adjustment
Technical date
1. Maximum service temperature:1100°C
2. Continuous working temp:1000°C
3. Compressive strength:0.8-3Mpa
4. Liner reheat shrinkage (24H @ 900°C %):<3
5. Total porosity (%):60-74
6. Thermal coductivity;@200°C 0.1-0.4
@400°C 0.12-0.16
@600°C 0.14-0.18
