General Introduction
Fast delivery high brightness flexible led strip orilighting Led
brightness flexible led strip
Specification
| Power Consumption | 14.4W/M |
| Work Voltage | DC12V |
| Work Current | 1.2A |
| Beam Angle | 140°-180° |
| LED Encapsulation | SMD 5050 |
| LED Quantity | 60LEDS/M |
| Color | Single Color(White,Warm White,Cold White,Red ,Green,Blue,Yellow,Pink),RGB |
| PCB Color | Yellow, White,Black |
| PCB Dimension | 50*10*2.5mm |
| Waterproof Grade | IP68 |
| Work Temperature | -25-60deg |
| Light Decay | Less Than 3% After 3,000H |
| Life-span | 50,000H |
| Certificate | CE&ROHS&ISO9001:2008&FCC |
| Every Roll | 5m |
| Warranty | 2 years |
| Luminous Flux | 720-900Lm/M (White) |
| 140-1800Lm/M (Red) | |
| 7200-900Lm/M (Green) | |
| 1200-140Lm/m(Blue) | |
| 140-1800Lm/M (Yellow) | |
| LED Spacing | 33mm |
| Min.Cutting Unit | 3LEDS |
| Min.Cutting Length | 10mm |
| Max.Connecting In Series | 5M ,Or More Than 5M,Please Connect Them In Parallel |
| Application | Path&contour marking |
| Indoor and outdoor sign | |
| Adverisement led backlight | |
| Architectrual decorative lighting | |
| Stairway accent lighting | |
| Channel letter lighting | |
| Message sign lighting |
Usage/Applications
Widely used for decoration lightings, sign lightings and so on.
High point of our led strip
1)Sealed to IP30.Humidity/Moisture resistant for indoor use
2)50,000 hours life
3)High Flexibility.
4)Very Low Energy Consumptio
5)Safe, Low Voltage Operation.
6)High visual impact
7)No RF interference
8)No UV light to avoid insects around
9)maintenance free ,With 3M adhesive tape backside,easy to install
10)Solid with high stock resistance
11)3 Leds cuttable with the mark and easy connecting with the snap-in connector and can be cut off at regular segments without damaging the rest ribbon.
12)Working with normal power supply and controller.
13)Available in many colors such white ,warm white ,cold white ,red ,green ,blue ,pink ,RGB and magic color etc.
