Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Excavators Hydraulic Crawler WY75
Model NO.:HTL150-8
Type:Wheel Excavator
Size:Medium-Sized
Certification:CE, ISO9001: 2000
Condition:New
Bucket Capacity: 0.6m³:with Color: Red or Yellow or as Your Request
Export Markets:Global
Trademark:HUNTER
Packing:40hq or in Bulk
Standard:CE, ISO9001: 2000
Origin:China
HS Code:84295211
Production Capacity:3000 Units/Year
15 ton Hydraulic wheeled excavator with CE aprroved (HTL150-8)Factory Export Directly.Features:1)Low noise, low fuel consumption and low emission.2)Adopted world class Kawasaki hydraulic system, high efficiency and reliability.3)Safe and comfortable driving cabin with air conditioner.4)Hydraulic control system is used with multi-power modes to adapt to different operations.5)Superior excavation performance, design of enhanced structural parts, uses high tensile steel plate Below shows for:1) On-site customer visit& test run 2) Factory Workshop3) Shipments4)We take part in exhibition.5) Product details
| Product Specifications | ||||||||||
| Model No. | Description | Unit | HTL150-8 | |||||||
| Main Dimensions | Shipping Length | mm | 7600 | |||||||
| Shipping Height | mm | 3450 | ||||||||
| Overall Width | mm | 2700 | ||||||||
| Tyre Type | mm | 8.25-20 | ||||||||
| Radius, Swing Center to Rear End | mm | 2250 | ||||||||
| Wheelbase | mm | 2620 | ||||||||
| wheeltread | mm | 1965 | ||||||||
| Steering Width | mm | 2500 | ||||||||
| Performance Parameters | Engine Type | YC4A125Z-T21 | ||||||||
| Power | kw/rpm | 92/2200 | ||||||||
| Hydraulic System Pressure | MPa | 34.3 | ||||||||
| Hydraulic System Flow | L/min | 126×2 | ||||||||
| Bucket Volume | m³ | 0.6 | ||||||||
| Bucket Digging Force | KN | 85 | ||||||||
| Arm Digging Force | KN | 53 | ||||||||
| Gradeability | (°) | 20 | ||||||||
| Rotation Speed | rpm | 11 | ||||||||
| Travel Speed | km/h | 20 | ||||||||
| Approximate Weight | kg | 14020 | ||||||||
| Working Scope | Max. Digging Height | mm | 9102 | |||||||
| Max. Dumping Height | mm | 6653 | ||||||||
| Max. Digging Depth | mm | 5023 | ||||||||
| Max. Digging Radius | mm | 8310 | ||||||||
| Buyer Reading: 1)Payment way : L/C, T/T 2)Delivery time: 5-30days after your deposit paid. It depends on your Quantity. 3)Shipping way: By sea, in 40HQ or Ro-Ro ships Thanks for your reading. More information contact us. | ||||||||||
