Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Excavators 15-20 Tons Crawler Hydraulic
Model NO.:ZE230E-9
Type:Crawler Excavator
Size:Large-Scale
Certification:ISO9001: 2000
Condition:New
Model:Crawler Hydraulic Excavator
Color and Logo:Can According to Customers′ Request
Export Markets:Global
Trademark:Veldlion
Packing:Nude
Standard:3C & ISO9001& CE
Origin:Hubei, China
Production Capacity:3000
1. We also supply you the other type of HOWO, 4*2, 4*4, 6*2, 6*4, 6*6, 8*4 different engine power(270HP, 290HP, 310HP, 330HP, 350HP, 380HP, and 420HP), EURO II, and EURO III dump truck. We could choose the right truck for you and confirm that is your good assistant in your work.
Our main products:
1. Heavy duty truck,
2. Fire engine truck
3. Truck mounted with crane
4. Dump truck
5. Water truck,
6. Fuel tanker,
7. Van truck, insulated truck, refrigeration truck
8. Fecal suction truck, sewage suction truck,
9. Concrete mixer truck,
10. High-altitude operation truck,
11. Self-loading garbage truck, garbage compactor truck, sealed garbage truck,
12. Bulk cement truck,
13. Chemical liquid tank truck
| Excavator | XE135B | |
| Operating weight | 13800 | kg |
| Standard bucket capacity | 0.4-0.52 | m 3 |
| Engine | ||
| Model | ISUZU BB-4BG1TRP | |
| Direct injection | √ | / |
| Four strokes | √ | / |
| Water cooling | √ | / |
| Turbo charged | √ | / |
| Air to air intercooler | × | / |
| No. of cylinders | 4 | / |
| Rated power/speed | 69.6/2200 | kw/rpm |
| Max. torque/speed | 337.6 | N.m |
| Displacement | 4.329 | L |
| The main performance | ||
| Travel speed | 5.16/3.03 | km/h |
| Swing speed | 12.3 | r/min |
| Max. gradeability | ≥35 | / |
| Ground pressure | 42 | kPa |
| Max.Bucket digging force | 85 | kN |
| Max.arm crowd force | 65 | kN |
| Max.traction force | 134 | kN |
| Hydraulic system | ||
| Main pump | 2 | / |
| Rate flow of main pump | 2×123 | L/min |
| Max pressure of prime relief valve | 31.4/34.3 | MPa |
| Max pressure of travel system | 34.3 | MPa |
| Max pressure of swing system | 25 | MPa |
| Max pressure of pilot system | 3.9 | MPa |
| Fuel tank capacity | 250 | L |
