Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Excavator CE Form China (K80SD)
Model NO.:XCG240LC-8
Type:Excavator
Usage:GM Excavator
Bucket:Backhoe
Transmission:Hydraulic Transmission
Drive Type:Internal Combustion Drive
Bucket Capacity:1.0~1.5m³
Size:Medium-Sized
Certification:ISO9001: 2000
Condition:New
Color:Green
Function:Earthmoving
Export Markets:Global
Trademark:KUDAT
Packing:Bulk
Standard:CE certificate
Origin:China
Production Capacity:500PCS/Year
24T operating hydraulic crawler excavator
Equiped original Cummins EUIII diesel engine
Full electic control
1.2M3 bucket capacity
125KW engine power
23.32T operating weight
| Rated bucket capacity | 1.2 m3 |
| Operating weight | 23320 kg |
| Engine | |
| Model | |
| Rated output | 125 kW@2100 rpm |
| Bore × stroke | 105x125 mm |
| Displacement | 6.494 L |
| Max. torque | 637.9 Nm |
| Batteries | 2×12 V |
| Hydraulic System | |
| Main Pumps | 2xVariable displacement axial piston pumps |
| Max. flow | 2x235 L/min |
| Hydraulic motors | |
| Travel motors | 2x Variable displacement axial piston motors |
| Swing motors | 1x Fixed displacement axial piston motor |
| Relief valve setting | |
| Implement circuit | 31.4 Mpa |
| Swing circuit | 25.5 Mpa |
| Travel circuit | 31.4 Mpa |
| Pilot circuit | 3.9 Mpa |
| Max. bucket digging force | 152.7kN |
| Max. arm digging force | 94 kN |
| Swing System | |
| Swing speed | 12.9 rpm |
| Drive | |
| Max. drawbar pull | 200 kN/20408kg |
| Travel speed | |
| High speed | 5.5 km/h |
| Low speed | 3.2 km/h |
| Grade ability | 35 |
| Undercarriage | |
| Carrier rollers | 2x2 |
| Track rollers | 2x9 |
| Track pads | 2x49 |
| Shoe width | 600 mm/800mm |
| Ground pressure | 47 kPa |
| Capacities | |
| Fuel tank | 390 L |
| Hydraulic tank | 190 L |
| Hydraulic system | 220L |
| Cooling system | 28 L |
| Engine oil | 21.5 L |
| Travel reduction unit | 2x5 L |
| Swing teduction unit | 4.4 L |
| Working Ranges | |
| Max. cutting height | 9360 mm |
| Max. dumping height | 6702 mm |
| Max digging depth | 6616 mm |
| Max. vertical wall digging depth | 5473 mm |
| Max. digging reach | 10088 mm |
| Max. digging reach on ground | 9920 mm |
| Min. front swing radius | 3951 mm |
| Standard boom | 5700 mm |
| Standard arm | 2900 mm |
| Dimensions | |
| Overall length | 9786 mm |
| Overall height of boom | 3256 mm |
| Overall Width | 2980 mm |
| Overall height of cab | 2946 mm |
| Counterweight clearance | 1130 mm |
| Min. ground clearance | 468 mm |
| Tail swing fadius | 3030 mm |
| Track ground length | 3640 mm |
| Track length | 4440 mm |
| Track gauge | 2380 mm |
| Track overall width | 2980 mm |
