Excavator CE 15ton with Isuzu Engine
Model NO.:w2150
Type:Crawler Excavator
Usage:GM Excavator
Transmission:Hydraulic Transmission
Drive Type:Internal Combustion Drive
Bucket Capacity:0.5~1.0m³
Size:Medium-Sized
Certification:CE, ISO9001: 2000
Condition:New
CE Standard Excavator:Hydraulic Excavator
Operation Weight:13600kg
Engine Power:100HP
Engine Brand:Isuzu
Hydraulic Pump:Kawasaki
Main Valve:Parker
Cabin:Air Conditioned
Export Markets:Global
Trademark:WORLD
Packing:Roro
Standard:ISO CE
Origin:China
HS Code:84295212
Production Capacity:5000PCS/Year
Ce standard Excavator
W2150 is a 15ton middle size excavator with 0.53 cubic meters bucket. The excavator adopts the original ISUZU BB-4BG1TRP engine which can supply 72.7kw power at the rated speed of 2200rpm. Automatic idle speed prevents unnecessary fuel consumption. The well known Kawasaki brand hydraulic pump supplies larger displacement to ensure the excavator stronger power and higher efficiency. Parker brand valve, Doosan brand travel motor and Sungbo brand swing motor match the pump perfectly. It is really a economic machine with high quality. It was widely used in urban construction and building.
Specifications:
| Engine System | |
| Brand & Origin | ISUZU(Japan) |
| Model | BB-4BG1TRP |
| Rated Power | 72.7/2200 kw/rpm |
| Max. Torque | 337.6/1600 Nm/rpm |
| Idling Speed | 1000rpm |
| Engine Displacement | 4.329 L |
| Cylinder No./-BorexStroke | 4-105mmx125mm |
| Engine Oil Capacity | 13.2L |
| Fuel Tank Capacity | 240L |
| Fuel Consumption Rate | 240 g/kw.h or less |
| Working Specifications | |
| Operating weight | 13600(Kg) |
| Bucket capacity | 0.53(m3) |
| Max. breakout force | |
| (1)Bucket digging force | 91.8(KN) |
| (2)Arm digging force | 65.3(KN) |
| Max. digging height | 8640(mm) |
| Max. dumping clearance | 6139(mm) |
| Max. digging depth | 5532(mm) |
| Max. vertical wall digging depth | 5102(mm) |
| Max. digging reach | 8330(mm) |
| Min. front swing radius | 2500(mm) |
| Max. pulling force | 113(kN) |
| Max.travel speed(double modes) | 3.1/5.3(km/h) |
| Max. grade ability | 70% |
| Overall dimensions | |
| Length(with bucket on ground) | 8330(mm) |
| Width | 2490(mm) |
| Bucket width | 854(mm) |
| Ground length (in transportation) | 7718(mm) |
| Height(To the top of the boom) | 2800(mm) |
| Height(To the top of the cab) | 2705(mm) |
| Counter weight ground clearance | 885(mm) |
| Track gauge | 1990(mm) |
| Tail swing radius | 2380(mm) |
| Min. ground clearance | 392(mm) |
| Rotating platform width | 2490(mm) |
| Counter weight height | 930(mm) |
| Crawler teeth thickness | 25(mm) |
| Reach from swing center to tail | 2380(mm) |
| Crawler ground length | 2840(mm) |
| Standard arm length | 3132(mm) |
| overall length of crawler | 7525(mm) |
