Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Electric Pallet Truck (Et18m 1800kg)
Model NO.:ET18M
Color:Green (Customized Accepted)
Battery:Maintenance Free
Charger:Built in
Export Markets:Global
Trademark:MICROLIFT
Packing:2 Sets/Pallet
Standard:CE, SGS
Origin:China
Production Capacity:100 Sets/Month
Capacity 1800KGS. Walkie Type. AC Motor. Full Electric Pallet Truck. High efficiency. It's used for middle and low frequency applications. Especially designed for replacing hand pallet trucks and semi hand pallet trucks.
| Characteristics | |||
| 1.1 | Manufacturer | MICROLIFT | |
| 1.2 | Model | ET18M | |
| 1.4 | Operate Type | Walkie | |
| 1.5 | Load Capacity | Q(kg) | 1800 |
| 1.6 | Load Center | c(mm) | 600 |
| 1.9 | Wheelbase | y(mm) | 1320 |
| Weight | |||
| 2.1 | Service Weight(Incl. Battery) | kg | 320 |
| Wheels,Chassis | |||
| 3.1 | Tyre Type | PU | |
| 3.2 | Tyre Size,Drive Wheels | mm | Φ230x70 |
| 3.3 | Tyre Size,Load Wheels | mm | Φ80x60 |
| 3.4 | Tyre Size,Balance Wheels | mm | Φ84x48 |
| 3.5 | Wheels,Numbers(x= drive wheel) | 1+2/4 | |
| Dimensions | |||
| 4.2 | Height,Mast lowered | h1(mm) | - |
| 4.3 | Free Lift | h2(mm) | - |
| 4.4 | Lift Height | h3(mm) | 205 |
| 4.5 | Height,Mast Extended | h4(mm) | - |
| 4.9 | Height of tiller arm,Min/Max | h14(mm) | 785/1250 |
| 4.15 | Fork Height, Lowered | h13(mm) | 85/74 |
| 4.19 | Overall Length | l1(mm) | 1625 |
| 4.21 | Overall Width | b1/b2(mm) | 680 |
| 4.22 | Fork Dimension | l/e/s(mm) | 1150x160x50 |
| 4.25 | Outside Fork Width | b5(mm) | 540/680 |
| 4.32 | Ground Clearance | m2(mm) | 35 |
| 4.33 | AST,1000X1200 pallet crossways | ast1(mm) | 1980 |
| 4.34 | AST,800X1200 pallet crossways | ast2(mm) | 1860 |
| 4.35 | Outer Turning Radius | wa(mm) | 1430 |
| Performance | |||
| 5.1 | Travel Speed, Laden/Unladen | km/h | 5.0/5.5 |
| 5.2 | Lifting Speed, Laden/Unladen | m/s | 0.04/0.05 |
| 5.3 | Lowering Speed, Laden/Unladen | m/s | 0.04/0.05 |
| 5.8 | Max Gradeability, Laden/Unladen | % | 8.0/16.0 |
| Drive | |||
| 6.1 | Drive Motor Rating S2 60Min | kw | 1.10DC/AC |
| 6.2 | Lifting Motor Rating S3 15% | kw | 0.85DC |
| 6.4 | Battery Voltage/Capacity(5h) | V/Ah | 24/80 |
| Others | |||
| 7.1 | Controller | PG/CURTIS | |
| 7.2 | Service Brake | Regenerating | |
| 7.3 | Parking Brake | Electromegnetic | |
