Loading Port:China Main Port
Payment Terms:TT OR LC
Min Order Qty:-
Supply Capability:-
| 1KG=2.2LB 1INCH=25.4MM | ||||
| Model | ZDYT3-3.5 | ZDYT3-4.0 | ZDYT3-4.5 | |
| Capacity | kg | 300 | ||
| Max.working height | m | 5.5 | 6 | 6.5 |
| Max.platform height | m | 3.5 | 4 | 4.5 |
| Overall Length | m | 1.53 | ||
| Overall Width | m | 0.7 | ||
| Overall Height | m | 1.64 | 1.81 | 1.98 |
| Platform size | m | 0.9×0.64 | ||
| Min ground clearance | m | 0.05 | ||
| Wheelbase | m | 1.24 | ||
| Turning radius | m | 0 | ||
| Driving motor | 2×24VDC/0.4KW | |||
| Lifting motor | 24VDC/2KW | |||
| Drive speed-stowed | kw/h | 4 | ||
| Drive speed-raised | kw/h | 1.1 | ||
| Raise/lower speed | sec | 17/19 | 20/22 | 23/25 |
| Battery | 2×12V/120Ah | |||
| Charger | 24V/12A | |||
| Driving wheel | mm | 230×80 | ||
| Front wheel | in | 6 | ||
| N.W | kg | 655 | 665 | 675 |
| Standard features: |
| Can intelligent control bus |
| Ratio control |
| charge indicator |
| Working meters |
| Troubleshoot supporting seat |
| Low Voltage alarm Auto |
| Emergency descending button |
| Safeguard of ultratemperature |
| Overload limiter |
