Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Dumper Tipper Truck 336 HP 6*4 13m3 25ton Dump/Heavy Truck (ZZ3257N2947)
Model NO.:ZZ3257N2947
Transmission Type:Manual
Power:Diesel
Load Capacity:21-30t
Emission Standard:Euro 3
Drive Wheel:6×4
Engine Capacity:>8L
Seats:≤5
Horsepower:251-350hp
Tire Type:Inner Tube
Tire Certification:ISO
Tire Design:Radial
Dumping Type:Front Lifting Style
Condition:New
Color:Option
Body Capacity:13.25m3
Loading:25ton
Export Markets:South America, Southeast Asia, Africa, Mid East, Eastern Asia
Trademark:Sinotruk
Packing:Packed in Nude
Standard:ISO
Origin:Shandong, China
HS Code:8704103000
Production Capacity:5000
The dump body can be 18m³ --25m³, engine power can be 266,290,336,371hps.
Indicate us your working condition and we will offer you a best suitable truck.
No. | Model | Driving type | Engine output | Dimension of body mm | |
1 | ZZ3257N2947 | 6X4 | 336HP | 4800X2300X1200 | |
MAIN SPECIFICATIONS | |||||
Chassis Model | ZZ3257N2947 | Steering | ZF8098 | ||
Engine | Brand SINOTRUK | Gross Vehicle Weight | 25000KG | ||
WD615.69 EUROII | Dead Weight | 8550KG | |||
Maximum Output | 336HP | Tyres | 12.00R20 Radial tyre | ||
Rated engine power | 247/2200 | Cab | HOWO70 no sleeper | ||
Air-condition | |||||
Transmission | HW15710 10forward & 2reverse | Max.Driving Speed | 80 km/h | ||
Front Axle | SINOTRUK Model:HF9 | Cargo box thickness | Rectangle box | ||
Max.loading:9000kg | Floor 8mm | ||||
Rear Axle | SINOTRUK Model:HC16 | Side 4mm | |||
Max.loading:32000kg | Hydraulic system | Made in china Underbody Tipping | |||
Overall Dimension(mm) | 6500×2496×2958 |
