Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Dump Truck with 32 Ton Loading Capacity
Model NO.:CLW51201GSW
Transmission Type:Manual
Power:Diesel
Load Capacity:31-40t
Emission Standard:Euro 2
Drive Wheel:6×4
Engine Capacity:＞8L
Seats:≤5
Horsepower:251-350hp
Tire Type:Inner Tube
Tire Certification:ISO
Tire Design:Tubeless
Dumping Type:Front Lifting Style
Condition:New
Tipping Type:Front Tipper or Middle Tipper
Volume of Dump Body:15cbm to 20cbm
Steel Grade:Q345b or High Tensile Steel 610 and 700
Shape of Dump Body:Square Shape or U-Shape Dongfeng Dump Truck
Color:Red/Green/White/Yellow
Hydraulic:Hyva Brand Cylinder
Brand Name:Dongfeng 6X4 Dump Truck, Tipper Truck
Cabin:with Sleeper Bed or Without Sleeper Bed
Air Conditioner:with Air Conditioner, or Without Air Conditioner
Drive Type:Rhd or LHD
Export Markets:Global
Trademark:CLW
Packing:Nake and Waxed Before on Board
Standard:CCC and ISO9001
Origin:Hubei
HS Code:8704230090
Production Capacity:1500units/Month
Features:
1, Made by high tensile strengh steel, Q345B, Q610, 700
2, heave duty loading capacity. Dump volume: 15cbm-20cbm.
3, square shape or U-shape design, nice appearance.
4, Hydraulic system: A set of HYVA Brand cylinder.
5, Factory directly selling, high quality and compective price.
6, Dongfeng Cummins engine, 290hp.
| Vehicle name | Dongfeng 6X4 Tipper truck, dump truck | Vehicle models | DFL1250A8 |
| Engine Model | ISDe290 30 290hp | ngine power (kw) | 247/273 |
| Emission standard | Euro II | Steering | ZF8098 hydraulic steering with power assistance |
| Cab | With one sleeper bed | Transmission | manual , 10 forward, 2 reverse |
| Overall dimensions(mm) | 8545*2496*3170 | Van internal dimensions (mm) | 5800,5600×2300×1100 |
| Total mass (kg) | 25000 | Rated loaded mass (kg) | 12600 12410 |
| Kerb weight (kg) | 12270 12460 | Approach angle / departure angle (°) | 19/23 |
| Wheelbase(mm) | 3825+1350 | Front overhang / Rear overhang (mm) | 1500/1870 |
| Maximum speed (km/h) | 75 | Axle-load(kg) | 6000 16000 (Dual-axles) |
| Tire number | 10 | Tire type | 11.00-20 11.00R20 12.00-20 12.00R20 |
| Front tread(mm) | 2022 2041 | Rear tread(mm) | 1830/1830 |
