Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Dump Truck HOWO 8x4 30ton
Product Details
Model NO.:8X4 MODEL
Transmission Type:Manual
Power:Diesel
Load Capacity:30t
Emission Standard:Euro 2
Drive Wheel:8×4
Engine Capacity:＞8L
Seats:≤5
Horsepower:351-450hp
Tire Type:Inner Tube
Tire Certification:ECE, GCC
Tire Design:Tubeless
Dumping Type:Front Lifting Style
Condition:New
Color:Red Yellow Green
Truck Type:Dump Truck
Type:Dump Truck Tractor Truck Truck Trailer
Material:Iron
Export Markets:South America, Eastern Europe, Southeast Asia, Africa, Mid East, Eastern Asia
Trademark:Sinotruck
Packing:Nude Packing
Standard:ISO TS16949
Origin:Jinan China
HS Code:8704223000
Production Capacity:100000 Unit/Year
Qingdao Hairon Automobile Sales Co., Ltd., is the distributor of STEYR, HOWO, and all SINOTRUK series trucks made by China National Heavy Duty Truck Corp. (CNHTC). We are a group corporation that combines industry and trade. Our products involve dump trucks, dump trailers, concrete mixers, semi-trailers and hauling trucks.
We markets products in more than 50 countries and districts all over the world, including Russia, Iran, Indonesia, Vietnam, Saudi Arabia, Algeria, Sudan, Angora, Turkey, Brazil, Peru, and Cuba.
We believe that our warm and professional service will bring you pleasant surprises as well as fortune.
Cooperate with us, You can get harmonious service like family.
| Model | 8x4 dump truck | ||
| Cabin | Four point s suspension HOWO Cabin with spring and air shock absorber, VDO panel | ||
| Adjustable steering, sun cover | |||
| Engine | Type: Diesel 4-stoke Direct injection,6-cylinder in line, Turbo-charging, Inner cooling. | ||
| Model: | WD615.69 | STEYR technology(CNHTC) | |
| MAX Horse power: | 336HP/247kw | ||
| Displacement(L): | 9.726liter | ||
| Max torque: | 1350NM@1100-1600rpm | ||
| Bore/stoke: | 126mm/130mm | ||
| Gear box | CNHTC | Max torque:1500NM | |
| Model: | HW15710 | ||
| Speed: | 10speed,2reverse | ||
| Axle(front/rear) | |||
| Front axle | HF9 STEYR technology front steering axle | ||
| Tandem | HC 16ton STEYR technology double reduction hub reductor driving axle | ||
| Clutch | D430 diaphragm type clutch | ||
| Brake | Service brake: Dual lines air brake | ||
| Parking brake: Spring-Power drum brake | |||
| Engine brake: Engine exhaust brake(EVB) | |||
| Steering | ZF8098, driver sit at the left hand side | ||
| Electric Equipment | |||
| Operating voltage: | 24Vnegative grounded | ||
| Starter: | 24V,5.4KW | ||
| Alternator | 28V,758W | ||
| Battery voltage | 12V/135Ah,cigar lighter | ||
| Frame | strengthen steel frame, designed according to tough road condition. | ||
| Tyre | 12+1 spare tyre with rim | ||
| 12.00-20 nylon tyre | |||
| Suspension system: strongthen heavy duty Leaf spring type | |||
| Front/Rear | 14,13/14,13/12 | ||
| Dump body: type of body : | |||
| Inside size of Body(mm): 7300x2300x1500,6x4mm, made of high intensity steel | |||
| Lifting type: Front lifter type hydraulic system. Refer to picture | |||
| Overall dimension(mm): 10245x2496x3170,3386(Length x width x height) | |||
| Wheelbase | 1800+3500+1350mm | ||
| Track: | |||
| Front/Rear | 2022/1830 | ||
| Approach/Departure angle | 19/18 | ||
| Front /Rear overhang | 1500/2095 | ||
| Max speed | 75km/h | ||
| Kerb weight: | 14860kg | ||
| Oil tank capacity | 300L fuel tank | ||
