Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Model NO.:HN4250NGB38C9M4
Transmission Type:Manual
Power:Diesel
Load Capacity:31-40t
Emission Standard:Euro 2
Drive Wheel:6×4
Engine Capacity:＞8L
Seats:≤5
Horsepower:351-450hp
Tire Type:Inner Tube
Tire Certification:ISO
Tire Design:Tubeless
Dumping Type:Front Lifting Style
Condition:New
Cargo Dimention:Follow Your Request
Engine:336-420
Cabin:Extended Cabin Optional
Export Markets:Global
Trademark:HOWO
Packing:Nude
Standard:SGS
Origin:Jinan, China
HS Code:8701909000
Production Capacity:500, 000 Unit/Year
| Truck Chassis | Driving type 6x4 | |||
| Cabin | HOWO 76 Standard cab, with two seats and one bed, with air condition | |||
| Vehicle Main Dimensions | Overall dimensions (L x W x H)mm | 8500x2495x3300 | ||
| Wheel base (mm) | 3825+1350 | |||
| Weight in KGS | Tare Weight | 12600 | ||
| Front axles HF9 loading capacity | 9000 | |||
| Rear axles HC16 loading capacity | 2x16000 | |||
| Total loading capacity | 35000 | |||
| Engine | Brand | SINOTRUK | ||
| Model | WD615.47 | |||
| Type | 4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling | |||
| Horse Power(HP)/(RPM) | 371HP | |||
| Emission standard | Euro II | |||
| Gearbox | HW19710, 10 forward & 2reverse | |||
| Clutch | Reinforced diaphragm clutch 430 | |||
| Steering Gear | power steering, hydraulic steering with power assistance | |||
| Fuel tank (L) | 300 | |||
| Tire | 12R22.5 tubeless tire 11pcs | |||
| Dump body | Dimension | Lx W x H | 5600x2300x1500 | |
| Thickness | Floor 8mm, side 6mm | |||
| Hydraulics | Tipping Type: Front tipping HYVA brand | |||
