Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Dump Truck Factory Directly HOWO / Tipper
Product Details
Model NO.:HOWO7, T7H, T5G, HOHAN
Transmission Type:Manual
Power:Diesel
Load Capacity:15-50 Ton
Emission Standard:Euro 2,3,4,5
Drive Wheel:4X2; 6X4; 8X4
Engine Capacity:＞8L
Seats:≤5
Horsepower:100-540HP
Tire Type:Solid Tire
Tire Certification:ISO
Tire Design:Radial
Dumping Type:Front Lifting Style
Condition:New
Steering:Left Steering; Right Steering
Cab:Man/Volvo/Benz Technology
Hopper Type:Flat/U Type
Cert.:SGS, Ec
Export Markets:South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Trademark:HOWO
Packing:Nude Packing
Standard:CCC
Production Capacity:20, 000 pcs/year
Cargo body size: 7300*2300*1200 mm / 7800*2300*1200 mm /7800*2300*1050 mm
Cargo wheel base:1800+3500+1350/1800+3800+1350/1800+4200+1350 mm
| Cab | HW76 | |||||
| Single sleeper with AC | ||||||
| Left Hand Drive | ||||||
| Cargo body size | ||||||
| Length | 7300 mm | 7800 mm | 7800 mm | |||
| Width | 2300 mm | 2300 mm | 2300 mm | |||
| Height | 1200(1500) mm | 1200(1500) mm | 1050 mm | |||
| Volume | 20.15(25.19) M 3 | 21.53(26.91) M 3 | 18.84 M 3 | |||
| Steel Thickness | ||||||
| Bottom | 8 mm | 8 mm | ||||
| Side | 4 mm | 4 mm | ||||
| Dimensions | ||||||
| Length | 10245 mm | 10745 mm | 10825 mm | |||
| Width | 2496 mm | 2496 mm | 2496 mm | |||
| Height | 3170 mm | 3190 mm | 3190 mm | |||
| Wheel base | 1800+3500+1350 mm | 1800+3800+1350 mm | 1800+4200+1350 mm | |||
| Gross Weight | 31000 kg | 31000 kg | 31000 kg | |||
| Use | Construction garbage Stone Rock Gravel Sand | Big Stone Big Rock Big Gravel Big Sand | ||||
| Engine | WD615-energy-efficient EURO 2- produced by Sinotruk | |||||
