Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Dump Truck China Best Camc with Narrow Star Type 6X2
Model NO.:6x2
Power:Diesel
Load Capacity:21-30t
Emission Standard:Euro 2
Drive Wheel:6×2
Engine Capacity:＞8L
Seats:≤5
Horsepower:351-450hp
Tire Type:Solid Tire
Tire Design:Tubeless
Dumping Type:Front Lifting Style
Condition:New
Driving:Right or Left Possible
Export Markets:North America, South America, Eastern Europe, Southeast Asia, Africa, Mid East, Eastern Asia, Western Europe
Trademark:CAMC
Packing:Nude
Standard:SGS, GOST
Origin:China
Production Capacity:500, 000 Unit/Year
| Cabin | ZZ3257N3647A | |||
| HW76 cab. Original luxury Volvo cab with a berth and an A/C. photo for your reference. | ||||
| Vehicle Main Dimensions | L×W×H(mm) | 8150×2500×3170 | ||
| Wheel track(mm) | 1830 | |||
| Wheel base(front/rear) (mm) | 3625+1350 | |||
| Approach/Departure angle(°) | 19/26 | |||
| Weight | Tare Weight(t) | 12.42t | ||
| Loading Capacity(t) | 40t | |||
| Front axles loading capacity(t) | 1× 9t | |||
| Rear axles loading capacity(t) | 33t | |||
| Max.Drinving Speed (km/h) | 85 | |||
| Engine | Brand | SINOTRUK | ||
| Model | WD615.69 | |||
| Type | 6-cylinder in-line with water cooling; 4-stroke direct injection; turbo-charging and inter-cooling | |||
| Horse Power(HP) | 336HP | |||
| Emission Standard | Euro II | |||
| Front Axle | HF9 drum axle | |||
| Rear Axle | HC16 design overall cast steel axle. | |||
| Gearbox | HW15710.10 block transmission, Ten Forward & Two reverse. | |||
| Clutch | Reinforced diaphragm spring clutch, diameter 430mm | |||
| Steering Gear | ZF8098,original made in German. Power steering, hydraulic steering with power assistance. | |||
| Fuel Tank(L) | 300L | |||
| Tire | Eleven units of 12.00-20 Nylon tires.(option:12.00R20) | |||
| Brakes | Service brake: dual circuit compressed air brake Parking brake: spring energy, compressed air operating on rear wheels Auxiliary brake: engine exhaust valve brake | |||
| Dump Body | ||||
| Thickness | Side | 6 mm in high tensile strength steel Q345B | ||
| Front | 6 mm in high tensile strength steel Q345B | |||
| Bottom | 8 mm in high tensile strength steel Q345B | |||
| Dump Body Size | L×W×H | 5600mm×2300mm×1500mm | ||
| Tipping Hydraulics | Tipping Type | Middle tipping type | ||
| Tipping System | Complete set of Local brand T type hydraulics system | |||
