Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
dump truck A7 30 t high quality
Model NO.:HOWO A7
Transmission Type:Manual
Power:Diesel
Load Capacity:30t
Emission Standard:Euro 2
Drive Wheel:4WD
Engine Capacity:6-8L
Seats:A7-W, 2 Seats with 1 Bed, with A/C
Horsepower:371HP
Tire Type:Inner Tube
Tire Certification:ECE, GCC, ISO, DOT
Tire Design:Radial
Dumping Type:Ventral Lifting System
Condition:New
Driving Type:6X4 ,Left Hand Driving
Transmission:10 Forward and 2 Reverse
Engine:371HP
Front Axle:Hf9
Driving Axle:Hc16
Tire:12r20
Dump Body Size:18m3(5200*2300*1500mm)
Cab:A7-W, 2 Seats with 1 Bed,with A/C
Export Markets:South America, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia
Trademark:Sinotruk HOWO A7
Packing:Nude Packing
Standard:CCC
Origin:China
HS Code:8704230090
Production Capacity:20000 Units Per Year
Brand; SINOTRUK HOWO A7
Driving type: 6*4
Transmission: 10 forward and 2 reverse
Front axle: HF9
Driving axle: HC16
Tire: 12R22.5
Dumper box: 18m3
Engine: 266-371hp
| Model | ZZ3257N3447N1 | |||||
| Driving type | 6x4 | |||||
| Driver's Cab | A7-W both the drive seat and the co driver seat have the double locking organization safety belts,sun visor,inner side sun shield, electronic glasses and electronic rear view mirror(with heating system),electronic lifting system of the cab,electronically hand throttle, the volume and the channed can be chosen through the steering wheel, the alarming system of the alternator when there is something wrong. | |||||
| Engine | Make: SINOTRUK | |||||
| Diesel 4-stroke direct injection diesel engine | ||||||
| Engine model: WD615.47, Euro 2 emission standard | ||||||
| 6-cylinder in-line with water cooling, turbo-charging and intercooling | ||||||
| Maximum output: 371 hp at 2200 rpm | ||||||
| Maximum torque: 1450 Nm at 1300-1600 rpm | ||||||
| Number of cylinder: 6 | ||||||
| Displacement: 9.726 L | ||||||
| Bore: 126 mm | ||||||
| Stroke: 130 mm | ||||||
| Specific fuel consumption: 198 g/kWh | ||||||
| Engine oil filling quantity: 23 l | ||||||
| Cooling system filling quantity (long-term filling): 40 l | ||||||
| Double cylinders air compressor | ||||||
| Rigid fan | ||||||
| Transmission | HW19710,10 forwards and 2 reverses,manual gearbox | |||||
| Ratio:14.28,10.62,7.87,5.88,4.38,3.27,2.43,1.8,1.34,1.00,13.91 ®,3.18® | ||||||
| Change the oil in the rotary gear box (transmission) after you have drive 2000-4000 kilometer | ||||||
| Front Axle | HF9,Steering with doubleT-cross section beam | |||||
| Rear Axle | Pressed axle housing, central single reduction with hub reduction and with differential locks between wheels and axles . | |||||
| Model:HC16 | ||||||
| Dumper box | 18m3(5200*2300*1500mm ,length* width*height) | |||||
