Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Dump Truck 8X4 (ZZ3317N3067W) Dumper Tipper China
Model NO.:ZZ3317N3067W
Transmission Type:Manual
Power:Diesel
Load Capacity:31-40t
Emission Standard:Euro 2
Drive Wheel:6×4
Engine Capacity:>8L
Seats:≤5
Horsepower:351-450hp
Tire Type:Inner Tube
Tire Certification:ISO
Tire Design:Radial
Dumping Type:Front Lifting Style
Condition:New
Body Volume:6500X2300X1200
Truck Type:Dump Truck
Type:Dump Truck
Export Markets:Global
Trademark:howo
Packing:Packed in Nude
Standard:ISO, CCC
Origin:China
HS Code:8704230090
Production Capacity:20, 000 PCS/Year
Reasonable allocated axle load, taking fully into account of the customers' requirement;
Low gravity, good driving stability;
Optimized hydraulic lifting system structure, low oil pressure, high lifting power and stable operating;
MAIN SPECIFICATIONS | |||||
Chassis Model | ZZ3317N3067W | Steering | ZF8098 | ||
Engine | Brand SINOTRUK | Gross Vehicle Weight | 31000KG | ||
WD615.47 EUROII | Dead Weight | 10080KG | |||
Maximum Output | 371HP | Tyres | 12.00R20 | ||
Rated engine power | 273/2200 | Cab | HOWO76(one bed) | ||
Air-condition | |||||
Transmission | HW19710 (10 forward, 2 reverse) | Max.Driving Speed | 75 km/h | ||
Front Axle | HF9 | Body | Floor 12mm | ||
Max.loading:9000kg | |||||
Rear Axle | HC16 | Side 6mm | |||
Max.loading:16000kg | Hydraulic cylinder | Front Tipping | |||
Overall Dimension(mm) | 8400×2496×3115 |
