Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Dump Truck 8X4 Tipper Truck, (QDT3310CZ74)
Model NO.:QDT3310CZ74
Transmission Type:Manual
Power:Diesel
Load Capacity:11-20t
Emission Standard:Euro 3
Drive Wheel:8×4
Engine Capacity:＞8L
Seats:≤5
Horsepower:251-350hp
Tire Type:Inner Tube
Tire Certification:ECE
Tire Design:Tubeless
Dumping Type:Front Lifting Style
Condition:New
Overall Dimensions(Mm):10428X2495X3480
Container Inner Dimensions(Mm):7400X2300X1140
Total Weight(Kg):31000
Rated Load(Kg):15940
Kurb Mass(Kg):14865
Container Volume(Cbm):17
Wheel Base(Mm):1860+3960+1350
Front Overhang/Rear Overhang(Mm):1438/1820
Chassis Model:Ca3310p2k2l4t4ea80
Drive Type:8X4
Export Markets:Global
Trademark:Qingte
Packing:Assembly
Standard:SGS
Origin:Qingdao, Shandong, China
HS Code:8716
Production Capacity:12, 000/Year
| Overall Parameters | |||
| Truck model | STQ3311L8T6B3 | Approach angle | 25° |
| Color | Red, Yellow | Departure angle | 30° |
| Overall dimension(L×W×H) | 10060mm×2490mm×3450mm | Kerb mass | 17500kg |
| Number of tires | 12 | Regular loading capacity | 40000kg~50000kg |
| Track width (front/rear) | 1940/1940/1880/1880mm | Max. loading capacity | 60000kg |
| Overhang (front/rear) | 1460mm/1850mm | Economical speed | 60km |
| Wheel base | 1850+3200+1350mm | Max. speed | 90km |
| ENGINE | |||
| Brand @ Model | Cummins @ LK375 33 | Intake way | Turbo-charge, inter-cooling |
| Rated power & speed | 375HP(276kw) & 2000rpm | Max. torque/speed | 1600N.m @ 1100-1600rpm |
| Engine type | in-line,4-stroke,water-cooled | Bore x Stroke | 116.5mm×148mm |
| Displacement | 6 cylinders,9.5L,diesel | Min. fuel consumption | ≤193(g/KM.h) |
| Emission standard | Euro-III | Fuel injection pump | Domestic |
| GEARBOX | |||
| Brand @ Model | FAST@Fuller @ 12JS160TA | ||
| Type | Manual,12 forward gear,2reverse gear,rated input tonque 1600N.M,with Power take-off | ||
| Gearbox ratio | First gear ratio: 12.1, 12th gear ratio: 0.78 | ||
| Clutch | Dry type,disc diameter Φ430mm | ||
| SUSPENSION SYSTEM | |||
| Front axle | Double 7T front axles | ||
| Rear axle | Reinforced double 16T hub reduction rear axles. Default axle Ratio: 5.92 | ||
| Front suspension | With shock absorber,Number/Thickness of leaf spring: 9/18mm | ||
| Rear suspension | With shock absorber,Number/Thickness of leaf spring: 12/25mm | ||
| BODYWORK DETAILS | |||
| Cargo box | Inner dimension of cargo box(L×W×H):6800mm×2300mm×1650mm,Volume:25.8CBM Cargo box thickness(floor/wall):10mm/8mm | ||
| Dump hydraulic system | Front-installed,Φ180mm, single cylinder,F580 gear pump | ||
| Cabin | T360 flat-roof,rear mechanical type suspension,3 seats,with sleeper | ||
| Chassis frame | Reinforced,Frame breadth 300mm,double-deck sheet(10mm+8mm),Frame width 860mm | ||
| Tire | 12.00R20-18 Aelous radius tire,8.5-20 wheel rim | ||
| Fuel tank | 430L,aluminium alloy | ||
| Exhaust system | Muffler, anti-scald board | ||
| Electrical system | 24V Voltage,2×12V/165Ah Battery | ||
| Brake system | 1.Service brake:dump-type air brake,2.Parking brake:spring type air shut-off brake, 3.Assistant brake:engine exhaust brake | ||
| EQUIPMENT | |||
| Power steering | Front & rear bumper | Spare tire | Windscreen wiper |
| Inter-axle differential | Oil pan protective cover | Tool | Electrical extinguisher |
| Inter-Wheel differential | Taillight protective cover | Engine tachometer | Cigar lighter & ashtray |
| Desert air filter | Air conditioner | Seat belt | AM/FM radio & player |
| Drier | Warm A/C | Front fog lamp | Horn |
| Sun visor | Power windows | Crystal headlamp | Reversing light & buzzer |
