Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Dump Truck 8X4 375HP Mining Rhd Dumper Tipper Truck
Model NO.:CLW5473
Transmission Type:Manual
Power:Diesel
Load Capacity:41-50t
Emission Standard:Euro 3
Drive Wheel:8×4
Engine Capacity:＞8L
Seats:≤5
Horsepower:351-450hp
Tire Type:Inner Tube
Tire Certification:ECE, GCC, ISO, DOT
Tire Design:Radial
Dumping Type:Front Lifting Style
Condition:New
Brand:Dongfeng
Color:Red, Yellow, Any Other Color as Your Require
Payload(Kgs):40-50ton
Chassis Brand:Dongfeng
Suspension System:Mechanical Suspension
Tire:12.00r20
Driving Mode:8X4
Place of Origin:Hubei China
Lifting:Hydraulic Lifting System
Manufacturer:Chengli Special Automobile Co., Ltd
Export Markets:Global
Trademark:dongfeng
Packing:Naked, Waxing and So on
Standard:BV, SGS
Origin:Hubei. China
HS Code:8704103000
Production Capacity:800sets/Month
| Basic information | ||
| Product Name | Dongfeng 8x4 375HP dump truck | |
| Product Model | DFL3310AX14A | |
| Drive type | 8x4 | |
| Gross weight | 31000kgs | |
| Rated load | 15990kgs | |
| Kerb weight | 14880kgs | |
| Wheelbase | 1850+4600+1350mm | |
| Overall size: | 10400x2500x3760mm | |
| Front trend | 2040mm | |
| Rear trend | 2040mm | |
| Approach/Departure Angle | 30/34(°) | |
| Cargo body | ||
| Length | 8200mm | |
| Width | 2300mm | |
| Height | 1000mm | |
| Type | Rear Dump type | |
| Engine | ||
| Engine | dCi375-30/Dongfeng | |
| Displacement | 11120ml | |
| Power | 276kw | |
| Horsepower | 375hp | |
| Fuel type | Diesel | |
| Emission standard | Euro 3 | |
| Gearbox | ||
| Gearbox | Fast 16JS180TA | |
| Forward gear/Reverse gear | 16/2 | |
| Tyre | ||
| Tyre no. | 12 | |
| Tyre specification | 12.00R20 | |
| Oil box | ||
| oil box capacity | 400L | |
