Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Dump Truck 8X4 336HP/247kw 12Wheels / Tipper Truck
Model NO.:HOWO 8X4
Transmission Type:Manual
Power:Diesel
Load Capacity:31-40t
Emission Standard:Euro 2
Drive Wheel:8×4
Engine Capacity:＞8L
Seats:≤5
Horsepower:251-350hp
Tire Type:Inner Tube
Tire Certification:ISO
Tire Design:Bias
Dumping Type:Front Lifting Style
Condition:New
Engine Optional:Euro2/3/4/5
Export Markets:North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia
Trademark:SINOTRUK
Packing:Nude Package
Standard:CCC
Origin:China
Production Capacity:20, 000 pcs/year
Optional:
Cargo body size: 6200*2300*1200 mm / 6500*2300*1200 mm /6800*2300*1200 mm
Cargo wheel base:1800+2800+1350/1800+3000+1350/1800+3200+1350 mm
| Performance | |
| Curb weight | 15200kg |
| Rated loading capacity | 31ton |
| Overall dimension (mm) | 10245L*2496W*3456H |
| Wheelbase(mm) | 1800+3500+1350 |
| Max. speed(km/h) | 75km |
| Max. gradeability (%) | 35 |
| Min. turning radius(m) | 24 |
| Specifications | |
| Driving mode | 8x4 |
| Hopper size/capacity (mm/cubic) | 7300*2300*1800/30 cubic, "F" type hydraulic lifting system |
| Cab | VOLVO type standard cab, one sleeper |
| Engine | WD615 336HP/247KW, Euro 2 engine |
| Transmission | HW15710 manual transmission |
| Clutch | Φ430 |
| Driving axle | Construction project type, Double reduction driving axle, 16ton loading capacity |
| Fuel tank | 300L diesel |
| Tire | 12.00-20 |
