Dump Truck 6X4 Tipper Truck 30ton

Loading Port:Shanghai

Payment Terms:TT OR LC

Min Order Qty:1 PCS

Supply Capability:1500 PCS/month

Product Description:

Dump Truck 6X4 Tipper Truck 30ton

Product Details

Basic Info.

Model NO.:DY3251



Transmission Type:Manual

Power:Diesel



Load Capacity:21-30t

Emission Standard:Euro 2



Drive Wheel:6×4

Engine Capacity:>8L



Seats:≤5

Horsepower:251-350hp



Tire Type:Inner Tube

Tire Certification:ISO



Tire Design:Radial

Dumping Type:Front Lifting Style



Condition:New

Cabin:European Driving Cabin



Engine:Weichai Brand

Gearbox:Fast Brand



Axles:Hande Brand

Tyre:12.00r20 Radial Tyre



Color:Red, Yellow, etc

Export Markets:South America, Southeast Asia, Africa, Mid East, Eastern Asia

Additional Info.

Trademark:DAYUN



Packing:Nude

Standard:Euro 2



Origin:China

Production Capacity:60000PCS/Year

Product Description

1,European driving cab
The European large cab is ergonomically designed and comfortable. It enables the cab to bear over 50% impact by means ofadopting all-metal frame, bird's nest structure design, domestic pioneering energy-absorbing bumper and four-point suspension structure. The designs all enable the cab's safety and comfort.

2,Spacious and comfortable sleeper design
Spacious sleeper in the cab and thickened sleeper pad enable the cab to be more comfortable for rest. Good sleeper fabric texture makes it more dirt resistant and durable. The fixing structure of upper bunk becomes more reasonable, the sleeper support and safety protection device are increased and the fixed mode of the sleeper sunshade is also improved.

3,Multi-bit precise-controlled instrument panel
An adjustable LED five-level circulation background lamp is used. The indicator indicates precise reading and self-testing can guarantee smooth operation.

4,Automatic Cruise Control System
The user can freely set driving speed and keep driving at fixed speed. The intelligent setting can reduce oil consumption and enhance driving stability.

DYX3251Main Technical Parameters
Curb Weight(kg)12055/12160/12275/12380/12500
Gross Vehicle Weight(kg)25000
Max. Speed(km/h)75
Max. Gradeability(%)35
Horsepower(ps)270\290\300\310\336\340\375\380
Engine TypeWP10.270 \WP10.290\WP10.336\WP10.270N\WP10.300N\WP10.336N\WP10.270E32\WP10.290E32\WP10.310E32\ WP10.340E32\WP10.375\WP10.380E32
Engine ManufacturerWeichai
Driving Type6X4
Driving Axle TypeDouble Reduction
Wheelbase(mm)3400+1350/3800+1350/4100+1350/4300+1350/4600+1350/5300+1350
Frame(mm)300X80X(8+8)/ 320X90X(8+8)[Wheelbase:5300+1350]
Overall Dimensions(mm)8235X2490X3270/8435X2490X3270/8635X2490X3270/9035X2490X3270/9335X2490X3270
Cargo Box Size(mm)5400X2300X1200/5600X2300X1200/5800X2300X1200/6200X2300X1000/6500X2300X1000
Tyre11.00R20\11.00-20\12.00R20\12.00-20
Main EquipmentsWeichai power\Fast gearbox\STR 7.5T single steering front axle\Hande 16T dual rear axle\Hydraulic steering\Pneumatic clutch\Manual air conditioner\Cab assembly(dump truck)
