Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Dump Truck 6X4 Tipper 380HP
Model NO.:CQ3254HTG384(A)
Model:Cq3254htg384(a)
Engine:C9 380
Gear Box:Rt-11509c
Tyre:12.00-20
Truck Type:Dump Truck
Type:Box/Stake Truck
Export Markets:Global
Trademark:IVECO Hongyan
Packing:Nude Packing, Waxing by RO-RO Ship or Bulk Ship.
Standard:CCC, ISO9001
Origin:China(Mainland)
HS Code:8704230090
Production Capacity:3000 Units/ Month
Model: CQ3254HTG384(A)
Driving type: 6X4
Cab: Short cab (one sleeper) A/C
Engine: C9 380
Displacement: 8.709 liters
Max. Output: 380HP@2200rpm
Specific fuel consumption(L/100KM): 32-41
Gear box: RT-11509C
Clutch: 430 spring type
Rear axle: 16T
Frame: 865mmx317mmx(8+8)mm
Tyre: 12.00-20
Kerb. Mass: 12090kg
Total mass: 25000kg
Wheel base (mm): 3775+1400
Front overhang (mm): 1435
Rear overhang (mm): 1765
Front track (mm): 2006
Rear track (mm): 1850/1850
Dimension (mm): 8375X2500X3510
| IVECO GENLYON C100 6×4 Heavy Dump Truck | |
| Drive type | 6×4 |
| Cabin | C100 flat cabin, automatic air-conditioning, with one sleeper |
| Engine ( CURSOR, Euro 3 ) | F2CE0681B*B052(C9 380) 8.709 Liters |
| 380 hp | |
| Transmission | 12JSD180T, 12 forward gears, 2 reverse gears |
| Overall Dimension (mm) | 8375×2500×3510(L×W×H) |
| Dump box dimension (mm) | 5600×2300×1500(L×W×H) |
| Dump box steel thickness | Bottom 8mm, side 6mm 50Tons Loading capacity. |
| Hydraulic lifting system | Front Lifting, HYVA front lifting hydraulic system |
| Loading capacity (kg) | 40~50 Ton |
| Wheel base (mm) | 3800 + 1400 |
| Front axle | 7 Ton |
| Rear axle | 16 Ton strengthen Dual-axis |
| Clutch | Φ 430mm Spring type |
| Overhang (mm) (F/R) | 1435 / 1765 |
| Tire | Radial tire 12.00R20 |
| Max. speed (km/h) | 75 |
| Fuel tanker capacity (L) | 350L |
