Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Dump Truck 6X4 25ton Hot Sale
Model NO.:ND3254B38
Transmission Type:Manual
Power:Diesel
Load Capacity:21-30t
Emission Standard:Euro 2
Drive Wheel:6×4
Engine Capacity:＞8L
Seats:≤5
Horsepower:251-350hp
Tire Type:Inner Tube
Tire Certification:ISO
Tire Design:Radial
Dumping Type:Front Lifting Style
Condition:New
Truck Type:Dump Truck
Type:Heavy Truck
Export Markets:Global
Trademark:North Benz
Packing:Nude Packing
Standard:Euro 2 or 3
Origin:China
Production Capacity:5000units/ Month
| Truck wheel base (mm) | 3800+1450 | ||||
| Curb weight kg | 12400 | ||||
| Engine | Model | WD12.375(Based on Styre technology, made in China) | |||
| Power, max kw/rpm | 206/2200 | ||||
| Max torque(Nm/rpm) | 1160/1100-1600 | ||||
| Emission standard | EUROII | ||||
| Fuel tanker capacity L | 300 | ||||
| Clutch | Model | GF420/GFX420, Single dry frictional disc,Hydraulic boosting | |||
| Gearbox | Model | RT11509C/9JS119/9JS180T/12JS160T ZFS6-90/ ZF5S-111GP/ 6T-90/ 6T-120 ZF 9S-109/ ZF 16S-1650/16S-221 | |||
| Transfer-case | VG1400(Benz technical,made by BEIBEN AXLE) | ||||
| Brake system | Service brake | Brake gap can be adjusted automatically, double circulation air brake system | |||
| Assistant brake | Engine exhaust brake | ||||
| Park brake | Potential springs pressing on middle and rear wheels | ||||
| Steering system | Model | ZF8098/ TAS85 | |||
| Frame of vehicle | Fish belly shape, variable width, variable section side beam structure | ||||
| Front axle (Mercedes Benz Technology) | Double-shoe pneumatic brake, non-driving steering axle | ||||
| Middle and Rear axle (Mercedes Benz Technology) | Double-shoe pneumatic brake, ductile casting casing, with hub redactor, double reduction driving axle | ||||
| Tyre | 12.00R20/12.00-20 | ||||
| Electrical system | Battery | 2X12V/135Ah | |||
| Generator | 28V-35A | ||||
| Starter | 5.4Kw/24V | ||||
| Cab | |||||
