Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Dump Truck 6X4 10 Wheel 336HP 18m3
Model NO.:ZZ3257N3447A1
Transmission Type:Manual
Power:Diesel
Load Capacity:21-30t
Emission Standard:Euro 2
Drive Wheel:6×4
Engine Capacity:＞8L
Seats:≤5
Horsepower:351-450hp
Tire Type:Inner Tube
Tire Certification:ECE, GCC, ISO
Tire Design:Radial
Dumping Type:Front Lifting Style
Condition:New
Truck Type:Dump Truck
Engine:Diesel
Horse Power:371HP
Export Markets:South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia
Trademark:Sinotruk
Packing:Packed in Nude
Standard:Euro 2
Origin:China
HS Code:8704230090
Production Capacity:20000 Per Year
| Model | ZZ3257N3447A1 | Bitmap |
| Cab | HW76,long cab with 2 seats and 1 bed.55 hydraulically tiltable to the front,2 arm windscreen wiper system with 3 speeds.with air conditioner | |
| Engine | Brand | Sinotruk |
| Model | WD615.47 | |
| Type | 4 stroke direct injection diesel engine,6 cylinder in-line with water cooling,turbo-charging & intercooling | |
| Horse power | 371HP | |
| Emission standard | Euro 2 | |
| Transmission | Model | HW19710,10 forward and 2 reverse |
| Front axle | HF9 | loading capacity:9000kgs |
| Driving axle | HC16 | loading capacity:2*16000kgs |
| Tire | Radial tire | 12.00R20 |
| Tubeless tire | 12R22.5 | |
| Brakes | Service brake | dual circuit compressed air assistance |
| Parking brake(emergency brake) | spring energy,compressed air operating on real wheels | |
| Auxiliary brake | engine exhaust brake | |
| Option | ABS | |
| Electrics | Operating voltage | 24V |
| Batteries | 2*12,165Ah | |
| Cigar-liggter,horn,headlamp,fog light,reverse lamp | ||
| Dump box size | 5200*2300*1500mm(18m3) with bottom 8mm side 4 mm | |
| Overall dimension of truck | 7835*2496*3300mm | |
| Lifting system | ventral lifting T type |
