Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Dump Truck 60 Series Mining 20ton Dumper Tipper
Model NO.:ZZ5607VDNB38400
Transmission Type:Manual
Power:Diesel
Load Capacity:50T
Emission Standard:Euro 2
Drive Wheel:4WD
Seats:≤5
Tire Type:Inner Tube
Tire Certification:ISO
Tire Design:Radial
Condition:New
Wheelbase(Mm):3400---3800
Truck Type:Dump Truck
Type:Box/Stake Truck
Export Markets:Global
Trademark:SINOTRUK HOVA
Packing:Packed in Nude
Standard:ISO9000, CE, CCC
Origin:Shandong, China
HS Code:87089099
Production Capacity:20000 PCS/Year
1. Broad, comfortable and safe cab with high strength and wide vision
2. HW19710 upgraded transmission can undertake bigger torque
3. Front shaft is I-style steel body with high strength
4. Bigger servo-brake and stronger brake thrust
5. Longitudinal rod of optimized design, high strength and longer service life
| Truck model | ZZ5607VDNB34400 | ZZ5607VDNB36400 | ZZ5607VDNB38400 | |
| Sale code | HV7/336/K34/6× 4D | HV7/336/K36/6× 4D | HV7/336/K38/6× 4D | |
| Size parameters | Overall dimension(mm) | 7760× 3000× 3450 | 8060× 3000× 3450 | 8460× 3000× 3450 |
| Dimension in container(mm) | 5100× 2800× 1500 | 5400× 2800× 1500 | 5800× 2800× 1500 | |
| Wheelbase(mm) | 3350+1500 | 3550+1500 | 3750+1500 | |
| Front/rear overhang(mm) | 1500/1560 | |||
| Min. ground clearance(mm) | 380 (Front axle) | |||
| Approach/departure angle(° ) | 29/35.5 | |||
| Weight parameters | Total weight/Max. rated contained quality(kg) | 20000/40000 | ||
| Performance parameters | Max. speed(km/h)/Max. gradeability(%) | 49 | ||
| Engine | Mode | WD615.69 | ||
| Rated engine power(kw/rpm) | 247/2200 | |||
| Max. torque(N. m/r/min) | 1350/1100~1600 | |||
| Fuel-rate(g/kw. h) | 198 | |||
| Clutch | 430 diaphragm spring clutch A-type, hydraulic control and gas assistance | |||
| Gearbox | Mode | HW19710 | ||
| Ratio | 14.28 10.62 7.87 5.88 4.38 3.27 2.43 1.8 1.34 1.00 R1 13.91 R2 3.18 | |||
| Drive axle/Front axle | 25T strengthened wide steel dual-reductors dual-tyres driving axle/12T strengthened steel I-style rigid front shaft | |||
| Overhang | strengthened front semi-oval steel spring, telescopic shock absorber, front stabilizing rod, strengthened rear whole balance suspension frame, 4 single-side obliquely installed U-bolts, rear stabilizing rod | |||
| Tire | 13.00-25 (as option) | |||
| Brake system | Driving brake: dual circuit brake; Parking brake: spring energy air cut brake; Assist brake: engine exhaust brake | |||
| Electric system | single line, 24V minus earth | |||
| Fuel tank | 400L | |||
| Min. diameter of turing(m) | 20 | 21 | 22.5 | |
