Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Dump truck (6 * 4, 8 ~ 10 t) in China Hot sale
Model NO.:ZZ3311M3261C1
Transmission Type:Manual
Power:Diesel
Load Capacity:31-40t
Emission Standard:Euro 2
Drive Wheel:8×4
Engine Capacity:＞8L
Seats:≤5
Horsepower:351-450hp
Dumping Type:Front Lifting Style
Condition:New
Export Markets:South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia
Trademark:SINOTRUK
Packing:Nude Packing
Standard:ISO
Origin:Shandong, China
Production Capacity:5000
1, Robust power;
2, reinforced axle and tipper body;
3, tested and proven tipping gear with low center of gravity.
| Weight Parameter | Complete Vehicle Kerb Mass(kg) | 15110 | |
| Maximum authorized total mass (kg) | 31000 | ||
| Maximum authorized towed total mass(kg) | |||
| Dimension Parameter | External Dimensions(mm) | Length | 9205 |
| Width | 2490 | ||
| Height | 3290,3490 | ||
| wheelbase(mm) | 1800+3200+1350 | ||
| Minimum Ground Clearance(mm) | 294 | ||
| Performance Parameter | Maximum Speed(km/h) | 75 | |
| Economical Speed(km/h) | 60 | ||
| Maximum Gradeability(%) | |||
| Turning diameter(m) | 6.42 | ||
| Recommended Configuration | Engine | Engine Type | WD615.92E WD615.92 WD615.93E WD615.93 WD615.92C WD615.93C WD615.97E WD615.97C |
| Rated power(kW)/Rev(r/min) | 196,196,213,213,198,213,221,221 | ||
| Maximum Torque(N*m)/Rev(r/min) | 1160/1300-1600, 1100/1300-1600, 1100/1100~1600, 1190/1200~1500,1290/1200~1500, 1160/1100~1600 | ||
| Transmission | HW15710 | ||
| Clutch(mm) | 430 | ||
| Rear Axle | Type | AC16 | |
| Speed Ratio | 4.77 | ||
| Fuel Tank(L) | 200 | ||
| Chassis Cross-section(mm) | 300 | ||
| Suspension(Front Back) | 1413/1413/12,11/11/12,4/4/-,11/11/- | ||
| Tyre | 11.00-20 18PR,11.00R20 18PR,12.00-20 18PR,12.00R20 18PR | ||
