Dump Truck 6 * 4 10 t quality assured
Model NO.:clw3257
Transmission Type:Manual
Power:Diesel
Load Capacity:21-30t
Emission Standard:Euro 3
Drive Wheel:6×4
Engine Capacity:＞8L
Seats:≤5
Horsepower:251-350hp
Tire Type:Inner Tube
Tire Certification:ECE, GCC, ISO, DOT
Tire Design:Radial
Dumping Type:Front Lifting Style
Condition:New
Description:Sino HOWO Dump Truck
Capacity of The Dump:20 Ton
Material of The Dump Body:Q235 Strength Steel
Tipping Type:Front Tipping Type
Vehicle Dimension:8545*2496*3386mm
Horse Power:310 HP
Wheel Base:3625+1350mm
Delivery Output:9726ml
Export Markets:Global
Trademark:CLW
Packing:Nude or Other Kind Pakaging as You Specified
Standard:CE/ISO...
Origin:Suizhou, Hubei Province
Production Capacity:200 Sets for One Months
Specifications
1. Dump truck
2. CCC&ISO certificate
3. Competitive price
Advantages for 6x4 SINOTRUK HOWO dump truck:
1. Heavy duty truck chassis
2. Reinforced body structure with proven telescopic tipping gear
3. Combination of ride comfort and power
4. Key pressure point reinforced cargo body
5. Robust powertrain can help you tackle any challange at the construction site
6. Stable and reliable under-body tipping device ensures low-gravity hoisting
| Code of the truck | CLW3257 HOWO | ||||
| Vehicle Main Dimensions | L×W×H(mm) | 8545×2496×3386 | |||
| Wheel base(front/rear) (mm) | 3800+1350 | ||||
| Overhang(front/rear)(mm) | 1430/1650 | ||||
| Wheel track(front/rear) (mm) | 2022/1850 | ||||
| Approach/Departure angle(°) | 19/19 | ||||
| Weight in KGS | Tare Weight(kg) | 12400 | |||
| Loading Capacity(kg) | 40000 | ||||
| Front axles loading capacity(kg) | 1×7000 | ||||
| Rear axles loading capacity(kg) | 2×18000 | ||||
| Max.Drinving Speed (km/h) | 80 | ||||
| Engine | Brand | SINOTRUK | |||
| Model | MC07.31-50 | ||||
| Type | 4-stroke direct injection; 6-cylinder in-line with water cooling; turbo-charging and inter-cooling | ||||
| Horse Power(HP) | 310HP) | ||||
| Emission Standard | Euro III | ||||
| Gearbox | block transmission, Ten Forward & Two reverse. | ||||
| Clutch | Reinforced diaphragm spring clutch, diameter 430mm | ||||
| Steering Gear | Power steering, hydraulic steering with power assistance. | ||||
| Fuel Tank(L) | 300L | ||||
| Tire | Eleven units of 11.00-20 tires.(option:11.00R20) | ||||
| Brakes | Service brake: dual circuit compressed air brake Parking brake: spring energy, compressed air operating on rear wheels Auxiliary brake: engine exhaust valve brake | ||||
| Dump Body | |||||
| Thickness | Side | 4mm in high tensile strength steel Q235 | |||
| Front | 4mm in high tensile strength steel Q235 | ||||
| Bottom | 8mm in high tensile strength steel Q235 | ||||
| Dump Body Size | L×W×H | 5600mm×2300mm×1125mm | |||
| Tipping Hydraulics | Tipping Type | Front tipping type | |||
| Tipping System | Complete set of Local brand front tipping type hydraulics system | ||||
