Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Dump Truck 340HP 6X4
Model NO.:6*4
Transmission Type:Automatic
Power:Diesel
Load Capacity:21-30t
Emission Standard:Euro 3
Drive Wheel:6×4
Engine Capacity:＞8L
Seats:≤5
Horsepower:251-350hp
Tire Type:Inner Tube
Tire Certification:ECE, GCC, ISO, DOT
Tire Design:Radial
Dumping Type:Front Lifting Style
Condition:New
Drive Type:6X4, Left-Hand Drive
Dimension:8457,8557X2500X3360
Tyre:12.00-20
Transmission:Fast 10jsd160
Engine:Yc6k1034-30,340HP
Steering:7.5t Drum Brke
Color:as Customers′ Request
Wheelbase:3825+1350(Mm)
Interior Dimension:5600, 5800*2300*1200
Thichness (Bottom/Side):Bottom 8mm, Side 6mm
Export Markets:South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Trademark:
Packing:Nude Packing
Standard:ISO, TS16949, CCC
Origin:Jiangsu, China
HS Code:8704230090
Production Capacity:1000PCS/Month
| Drive Form | 6×4 | |
| Dimension(mm) | Overall dimension | 8457,8557×2500×3360 |
| Wheel base | 3825+1350 | |
| Weight (kg) | Curb weight | 12050 |
| Max Speed (km/h) | 80 | |
| Max. slope of climb(%) | ≥35 | |
| Min. turning diameter(m) | 18 | |
| Engine and auxiliary facilities. | Engine Model | YC6K1034-30 |
| Displacement (L) | 10.338 | |
| Max torque (N.m/rpm) | 1550 | |
| Power(HP/KW) | 340 | |
| Clutch | brand:SACHS Common silicone style | |
| Air Filter | Desert style | |
| Oil Separator | Common style | |
| Cluth | Pull type diaphragm430 | |
| Transmission+ PTO | Model | MT Iron shell |
| Specification | brand:FAST 10JSD160 | |
| Drive axle | Specification | LC300 Drum brke/casting axle shell |
| Final drive ratio | 5.26 | |
| Suspension System | Specification | 12/13 |
| Frame | 300×80×(8+8) | |
| Steering axle | 7.5T Drum brke | |
| Brake system | Electronic brake | NA |
| Brake valva | brand:SACHS | |
| Air cylinder | Steeliness | |
| Steering booster | Domestic | |
| Wheel | Tire | 12.00R20 |
| Wheel | Steeliness | |
| Chassis and other items | Oil tank | 300L |
| Cab | Specifications | Flat roof medium long |
| Configuration | Standard | |
| Rear window | NA | |
| Front bumper | High order position | |
| Upper body Specification | Interior dimension | 5600, 5800*2300*1200 |
| lift type | Front lift | |
| Cylinder | 180 Domestic | |
| Thichness (bottom/side) | bottom 8mm, side 6mm | |
