Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Dump Truck 30 Ton Truck with 18m Cubic
Model NO.:CA3256
Transmission Type:Manual
Power:Diesel
Load Capacity:21-30t
Emission Standard:Euro 3
Drive Wheel:6×4
Engine Capacity:＞8L
Seats:≤5
Horsepower:251-350hp
Tire Type:Inner Tube
Tire Certification:ISO
Tire Design:Radial
Dumping Type:Front Lifting Style
Condition:New
Truck Type:Dump Truck
Brand:Faw
Steering:LHD, Rhd
Driving:6X4
Color:Red, White, Blue
Capacity:20-30 T
Export Markets:South America, Southeast Asia, Africa, Mid East, Eastern Asia
Trademark:
Packing:Nude
Standard:ISO
Origin:China
HS Code:8704230090
Production Capacity:300unit/Month
1. STEYR Tech WEICHAI 340, 380HP
2. EATON clutch
3. America parts
4. STEYR tech FULLER gearbox
5. Front lift or middle lift
6. Steel Cabin for comfortable drive
7. WABCO valve
8. USA TRW steering
9. NORGREN solenoid valves
10. Korean GLOBAL free-maintenance battery
11. American TFLOCK self-locking nuts
12. American WOODWARD speed governor
13. GEMAN VOITH retarder
14. American TUTHILL cable
15. CVG American driver seat
16. American TENNECO shocker
17. AMP plug connector
| TRUCK SPECS | Overall dimension: | 8345x2496x3450mm | |
| Cabin | Cabin size: | standard cabin(2 seats)/ long cabin(2 seats and 1 bed)/ | |
| Air conditioner: | standard | ||
| Engine | Horsepower(hp): | 340 360 380 | |
| Tech: | steyr tech,WD615 | ||
| Engine Type: | 6-cylinder in line, 4-stroke, water-cooled,turbocharged, intercooled | ||
| Steering: | USA TRW | ||
| Emission Standard: | EUR 2,3,4 | ||
| Fuel Type: | Diesel | ||
| Max Torque: | 1500N.m | ||
| Engine Capacity(ml): | 9726 | ||
| Gear Box/Transmission | 9/12 speeds and 2 reverse speeds | ||
| steering: | TRW hyraulic steering with power assistance | ||
| Clutch | EATON Φ430 | ||
| Axles | Front Axles: | 9T | |
| Driving Axles: | 2x16T | ||
| Tyre: | 12R22.5,10 Tubeless tires with one spare tire/ 12.00R20,10 Radial tires with one spare tire | ||
| Max speed: | 75/80/85km/h | ||
| Tare weight(MT): | 12MT | ||
| BODY SPECS | Body Dimensions (LengthXWidthXHeight): | 5600x2300x1500mm/ 5400x2300x1500mm | |
| Body steel (mm): | Q235 | floor 8mm(0.32in),side 6mm(0.24in) | |
| Cpacibility(M3): | 15CBM 20CBM | ||
| Lift System: | Middle hydraulic system with power assistance/ Front hydraulic system with power assistance | ||
| Wheel base: | 3825+1350mm | ||
| Track Width(front/rear): | 2041/1830mm(7.91x6ft) | ||
| Overhang(front/rear): | 1500/1870mm(7.55x6.14ft) | ||
| Approach/Departure Angle: | 19°/23° | ||
