Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Dump Truck 20m3 Environmental Tipper 6X4
Model NO.:ZZ3257N3847D1
Transmission Type:Manual
Power:Diesel
Load Capacity:41-50t
Emission Standard:Euro 4
Drive Wheel:6×4
Engine Capacity:＞8L
Seats:≤5
Horsepower:251-350hp
Tire Type:Inner Tube
Tire Certification:ISO
Tire Design:Radial
Dumping Type:Front Lifting Style
Condition:New
Chassis Brand:Cnhtc Sinotruk HOWO
Engine:249kw / 340HP
Gerbox:10 Forward Gears, 2 Reverse Gear
Drivre Axle:Hc16
Cargo Body Size:5600/5800*2300*1500/1800mm
Cargo Body Volume:20cubic-24cubic
Thickness:Side 6mm;Bottom 8mm
Lifting System:with Front Hydraulic RAM
Hydraulic Cylinders:Optional Hyva Brand
Side Door:Optional
Export Markets:Global
Trademark:SUNY
Packing:After Waxing by Container, RO-RO, Bulk Freighter
Standard:ISO&CCC
Origin:Hubei Suizhou
Production Capacity:500 Unit / Month
Diesel engine, 249kw / 340hp,10-speed Manual Gearbox,Dual-circuit air brake,24V.
Size:5600/5800*2300*1500/1800mm ,
20CBM Dump Truck,22CBM Dump Truck,24cbm Dump Truck/Tipper truck
| Products Technical Specification | ||
| Brand-Series | SINOTRUK HOWO 6*4 DUMP TRUCK | |
| Chassis Model | ZZ3257N3847D1 | |
| Emission Standard | Euro 4 | |
| Fuel type | Diesel | |
| Cabin | HW76 with A/C,one bed | |
| Whole vehicle main dimensions (mm) | Overall dimensions (L×W×H) | 8545*2496*3450 |
| Cargo body dimensions | 5600/5800*2300*1500/1800 | |
| Wheel base | 3825+1350 | |
| Front overhang | 1500 | |
| Rear overhang | 1870 | |
| Min. ground clearance | 530 | |
| Weight data (kg) | G.V.W | 25000 |
| Curb weight (chassis) | 12440 | |
| Max payload | 30000-50000 | |
| Whole vehicle main performance | Max. speed (km/h) | 80 |
| Max. slope of climb (%) | 30 | |
| Engine | Model | D10.34-40 |
| Maximum power | 249kw / 340hp | |
| Number of cylinders | 6 | |
| Displacement (L) | 9.726 | |
| Engine Manufacturer | CNHTC | |
| Transmission | Brand and Model | HW19710 |
| Number of gears | 10 forward gears, 2 reverse gear.(Manual) | |
| Axle | Rear Load capacity (ton) | HC16 |
| Suspension | Front | 10- Leaf spring |
| Rear | 12- Leaf spring | |
| Steering Wheel | left/right hand drive | LHD |
| Brake system | Service brake | Dual circuit compressed air brak |
| Electric device | Rated voltage | 24V |
| Tyres & Quantity | 12.00R 20 & 10+1 | |
| Cargo body Description | ||
| Cargo body dimensions (mm) | 5600/5800*2300*1500/1800 | |
| Cargo body material | Equipped with material of carbon steel Q235 | |
| Cargo body thickness | Side 6mm thickness;bottom 8mm thickness | |
| Lifting System | Equipped with Front hydraulic ram, one back door and two side door. | |
| Optional Configuration | ||
| HYVA Lifting System,Radial tires,Van thickness,side door,middle hydraulic ram,etc. | ||
