Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Model NO.:AKL20019GXL
Transmission Type:Automatic
Power:Diesel
Load Capacity:41-50t
Emission Standard:Euro 5
Drive Wheel:6×4
Engine Capacity:＞8L
Seats:≤5
Horsepower:351-450hp
Tire Type:Inner Tube
Tire Certification:ISO
Tire Design:Radial
Dumping Type:Front Lifting Style
Condition:New
L×w×h(Mm):7445X2496X3490
Max.Drinving Speed (Km/H):78
Fuel Tank(L):300L
Approach/Departure Angle(°):20/29
Export Markets:South America, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia
Trademark:AVIC KAILE
Packing:Nude
Standard:CCC, SGS, ISO9001
Origin:Anhui, Fuyang
HS Code:8704230090
Production Capacity:300 Unit/Month
| Cabin | Model: ZZ3257N3047N2 | |||
| A7-B cab.Original luxury cab with air-condition. | ||||
| Vehicle Main Dimensions | L×W×H(mm) | 7445x2496x3490 | ||
| Wheel base(mm) | 2975+1350 | |||
| Front track (mm) | 2022,2041 | |||
| Rear track (mm) | 1830/1830 | |||
| Approach/Departure angle(°) | 20/29 | |||
| Weight in KGS | Tare Weight | 11940kg | ||
| Total Weight | 25000kg | |||
| Front axles loading capacity | 1×7000 | |||
| Rear axles loading capacity | 2×9000 | |||
| Max.Drinving Speed (km/h) | 78 | |||
| Engine | Brand | HOWO-A7 | ||
| Model | WD615.95/96 | |||
| Type | 6-cylinder in-line with water cooling;4-stroke direct injection;turbo-charging and inter-cooling | |||
| Horse Power(HP) | 336/375 HP | |||
| Emission Standard | Euro III | |||
| Axle | AC16, Han Ruisen disconnect suspension, HF9 drum | |||
| Gearbox | HW15710/HW19710 | |||
| Clutch | Reinforced diaphgragm clutch, diameter 430mm | |||
| Steering Gear | ZF8098, original made in German.Power steering, hydraulic steering with power assistance. | |||
| Fuel Tank(L) | 300L | |||
| Tire | 12.00-20 18PR,12.00R20 16PR | |||
| Brakes | Service brake: dual circuit compressed air brake;Parking brake: spring enengy, compressed air operating on rear wheels;Auxillary brake: engine exhaust valve brake | |||
| Dump Body | ||||
| Thickness | Side | 6mm in high tensile strength steel Q235A | ||
| Front | 6mm in high tensilestrength steel Q235A | |||
| Bottom | 8mm in high tensile strength steel Q235A | |||
| Dump Body Size | L×W×H | 4800×2300×1400 (mm) | ||
| Tipping Hydraulics | Tipping Type | Former lift, discharge after | ||
| Tipping System | Complete set of HYVA brand hydraulics system | |||
