Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Dump Truck (15.5m3) Zz3257n3247b
Model NO.:ZZ3257N3247B
Transmission Type:Manual
Power:Diesel
Load Capacity:25t
Emission Standard:Euro 2
Drive Wheel:4WD
Engine Capacity:4-6L
Seats:2 Seats
Horsepower:351-450hp
Tire Type:Inner Tube
Tire Certification:ISO
Tire Design:Radial
Dumping Type:Front Lifting Style
Condition:New
Truck Type:Dump Truck
Type:Dump Truck
Model:Zz3257n3247b
Cab:Hw70,2 Seats,with Air Conditioner
Export Markets:South America, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia
Trademark:SINOTRUK
Packing:Nude
Standard:ISO
Origin:China
HS Code:8704230090
Production Capacity:20000
Model:ZZ3257N3247B
Cab:HW70,2 seats,with air conditioner
Engine:336hp/371hp
Transmission:10 forward and 2 reverse
Frotn axle:HF9
Driving axle:HC16
Tire:12.00-20
Dump box size:15.5m3(5200*2300*1300mm)
Loading capacity:25ton
| Weight | Curb Weight(kg) | 8800 | |
| Gross Vehicle Weight(kg) | 25000 | ||
| Gross Combination Weight(kg) | 50000 | ||
| Dimension | Overall Dimensions(mm) | Length | 6800 |
| Width | 2496 | ||
| Height | 2958(3718) | ||
| Wheel Base(mm) | 3225+1350,3200+1400 | ||
| Minimum Ground Clearance(mm) | 298 | ||
| Performance Parameters() | Maximum Speed(km/h) | 102 | |
| Economic Speed(km/h) | 82 | ||
| Maximum Gradability(%) | 35 | ||
| Minimum Turning Diameter(m) | 15 | ||
| Specification | Cabin | HW76(2 seats and 1 bed) | |
| Engine | Model | WD615.87 | |
| Net Power(Hp)/Rotating Speed(r/min) | 290/2200 | ||
| Maximum Torque(Nm)/Rotating Speed(r/min) | 1160/1100-1600 | ||
| Gearbox | HW15710 | ||
| Clutch(mm) | 430 | ||
| Rear Axle | Type | ST16 | |
| Gear Ratio | 4.42 | ||
| Oil Tank(L) | 400 | ||
| Tires | 12.00R20, 12.00R22.5, 295/80R22.5, 315/80R22.5 | ||
