Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Digger Hot Sales CT45-7b (4.5t)
Model NO.:CT45-7B hydraulic mini excavator with cabin
Type:Crawler Excavator
Usage:GM Excavator
Bucket:Backhoe
Transmission:Hydraulic Transmission
Drive Type:Internal Combustion Drive
Bucket Capacity:0.07m3--0.3m3
Size:Small-Scale
Certification:CE, ISO9001: 2000
Condition:New
5500*1750*2455(L*W*H):Ground Clearance350 Mm
Operating Weight 4200 Kg:Tracking Force 34.1kn
Travel Speed:4.4/2.7 Km/H:Arm Digging Force:20.4kn
Boom Length 2560 Mm:Arm Length 1450 Mm
Engine Power 27.1kw@2.200rpm:Gradeability 30(58%)
Bucket Digging Force 23.7 Kn:Ground Pressure 36kpa
Swing Speed 11rpm:Flow/Pressure10.8L/Min@2200rpm/4.9MPa
Rear Swing Radius 1.600 Mm:Tumbler Distance 1.710 Mm
Max Dozer Lifting Height 255 Mm:Max Dozer Cutting Depth 380 Mm
Export Markets:Global
Trademark:CARTER
Packing:Load 3 Units in One 40hq Container
Standard:CE, ISO9001
Origin:Shandong, China
HS Code:8429521200
Production Capacity:500 PCS/Year
CT45-7B MINI EXCAVATOR
1. Japan made Yanmar engine 4TNV88
2. Imported hydraulic components
3. On-line digital monitoring and control system
4. GPS satellite(optional)and remote control diagnose system(optional)
5. Rubber pedrail(optional, or steel pedrail), no damage to the ground of road
6. Full opened engine hood and easy up-forward-lifted cab
7. Cold&warm air conditioner
| Specification of CT45-7B with cabin | |
| Operate weight kg | 4200 |
| Bucket capacity M3 | 0.17 |
| Engine model | YANMAR 4TNV88 @27KW |
| Engine power(kw) | 27 |
| Swing spreed(rpm) | 11 |
| Ground pressure(Kpa) | 29 |
| Travel speed(km/h) | 4.4/2.7 |
| Tracking force(kn) | 34.1 |
| Gradeability(°) | 30 |
| Main dimensions | |
| Upperstrcuture witdth(mm) | 1600 |
| Undercarriage width(mm) | 1750 |
| Cabinet hight(mm) | 2455 |
| Rear swing radius(mm) | 1600 |
| Ground clearance(mm) | 350 |
| Working range | |
| Max.digging radius(mm) | 5530 |
| Max.digging depth (mm) | 3405 |
| Max.digging height(mm) | 5030 |
| Max.dumping height(mm) | 3410 |
| Max.dozer cutting depth(mm) | 380 |
| Max.dozer lifting hight(mm) | 255 |
| Standard Equipment | |
| Japanese KYB main pump | |
| Japanese KYB tracking motor | |
| Japanese KYB swing motor | |
| Italian valve ,pilot control lever | |
