Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:50 unit
Supply Capability:10000 unit/month
Residential ESS CFE-1280S 12.8V 100Ah 1280Wh
l Volumetric Energy Density increased by 23.5%
l LED power display screen and switch buttons
l Rugged stainless steel body ensures 5 years warranty
l High protection level IP65
l Support 1C charge / discharge and excellent heat dissipation design
l Quick connection and insulation protection
l Stainless steel handles guarantees 3000 fatigue tests
l Supports four external connections in series with voltage up to 51.2V
Product Spec | |
Name | CFE-1280S |
Model | 12.8V100Ah |
Nominal Voltage | 12.8V |
Nominal Capacity @1C | 100Ah |
Charge Voltage | 14.8V |
Charge Current Max Continuous | 50A |
Discharge Current Max Continuous | 100A |
Discharge Voltage Minimum | 10.8V |
Pulse Current 5 Sec | 150A |
Weight | 12.3kg±0.5kg |
Dimensions L*W*H（mm） | 320*140*210 |
Advantages:
• Ultra-reliable Lithium Iron Phosphate (LiFePO4) technology
• Integrated battery management System (BMS)
• Ultra-long cycle life
• Light weight & compact
• Water & dust resistant (IP56)
• Highly durable ABS enclosure
• Drop-in lead acid replacement
• Environment friendly
• Bluetooth App is optional*
• Household energy storage
• Telecom backup system
• Mobile base stations
• Emergency backup energy sources
• Uninterruptible power system
• Grid load shifters
• Electric Golf Car
• Electric vehicles
• Electric motorcycles
• Electric forklifts
• Electric boats, etc.
