Crawler Excavator 8ton with CE Approved CT80-7b
Model NO.:CT80-7B
Type:Crawler Excavator
Usage:GM Excavator
Transmission:Mechanical Transmission
Drive Type:Internal Combustion Drive
Bucket Capacity:0.1~0.5m³
Size:Small-Scale
Certification:CE
Condition:New
Color:Yellow
Function:Earthmoving
Export Markets:Global
Trademark:KUDAT
Packing:Bulk
Standard:SGS CE
Origin:China
Production Capacity:500PCS/Year
Original Yanmar engine complies with strong power, high effiency, lower failure rate, low oil comsumption, lower noise
Imported hydraulic pumps, valves, motors ensure high, performance
Capacious and comfortable cabin with air conditioner
Advanced electric control system realizes the auto idling function, reduction fuel consumption
| Specification | |
| Operating weight | 6820kg |
| Standard bucket capacity | 0.26m 3 |
| Track shoe width | 400mm |
| Arm length | 1700mm |
| Boom length | 3260mm |
| ENGINE | |
| Model | Yanmar 4TNV94L |
| Type | Natural aspirated |
| Number of cylinder | 4 |
| Max. power/rpm | 37.9kw/2200rpm |
| Max. torque | 217N.M at 1000 rpm |
| Displacement | 3.054L |
| HYDRAULIC SYSTEM | |
| Main pumps | |
| Type | Variable displacement axial piston pumps |
| Max. displacement | 63cm 3 /r |
| Working pressure | 25Mpa |
| Hydraulic motor | |
| Slew | Fixed displacement axial piston motor |
| Travel | Variable displacement axial piston motors |
| Performance | |
| Slew speed | 12 rpm |
| Min. back slew radius | 1650 mm |
| Max. travel speed high/low | 4.8/2.6km/h |
| Grade ability | 35 ° |
| Traction force | 46.3kn |
| Max. digging force of bucket | 44.5kn |
| Max. digging force arm | 30.7kn |
| Ground pressure | 0.337kg/cm 2 |
| Tank capacity | |
| Fuel tank capacity | 135L |
| Hydraulic tank capacity | 95.8L |
