Loading Port:China Main Port
Payment Terms:TT OR LC
Min Order Qty:-
Supply Capability:-
| Packaging Detail: | nude package and wooden cases |
| Delivery Detail: | 30 days after receiving the deposite |
hydraulic steel compressor
1.flange connection and no oil leak
2.unique cushioning device
3.feed box size can be customi
Pls be clear Manual operation or PLC automatic control?
Better to inform us your daily capacity & material pictures when you consult.
there are 3 ways for bale coming out, pls make sure the way you want. (if you are confused, pls contact us freely for the explaination.)
a: Bale front pushing out (only for small model)
b: Bale side pushing out
c: Bale side turn out
Y81 Series Hydraulic Scrap Metal Baler | ||||||
No. | Type | Nominal force(KN) | Power (KW) | Feed Box Size (mm) | Bale Size (mm) | Output(kg/h) |
1 | Y81-1250 | 1250 | 15 | 1200*700*600 | 300*300 | 800-1500 |
2 | Y81Q-1350 | 1350 | 22 | 1400*600*600 | 600*240 | 1500-2200 |
3 | Y81-1600A | 1600 | 22 | 1600*1000*700 | 350*350 | 2000-3000 |
4 | Y81-1600B | 1600 | 22 | 1600*1200*800 | 400*400 | 2000-3000 |
5 | Y81-2000 | 2000 | 37 | 1800*1400*900 | 450*450 | 2500-3500 |
6 | Y81-2500 | 2500 | 44 | 2000*1400*900 | 500*500 | 3000-5000 |
7 | Y81-3150 | 3150 | 60/66 | 2000*1750*1200 | 500*500 | 3500-5000 |
8 | Y81-4000C | 4000 | 90 | 3000*2000*1200 | 600*600 | 6000-8000 |
9 | Y81-6000 | 6000 | 135 | 5000*2000*1200 | 700*700 | 8000-10000 |
Note: 1. Please choose the model according to different demand. 2. Manual or PLC automatic control can be chosen! | ||||||
