Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Compactor Garbage Truck for Rubbish Collecting
Model NO.:JHL5250ZYS
Type:Compactor
Certification:ISO9000, CCC, TS16949, EPA, EEC, RoHS, CE
Volume:＞15000L
Emission Standard:Euro 2
Transmission Type:Manual
Engine Type:4 Stroke
Payload:20T
Fuel:Diesel
Drive Wheel:6×4
Brand:Sinotruk
Models:Large
Usage:Compression Type
Chassis:Zz3257m3247c
Condition:New
Size:8325X2490X3500mm
Tank Capacity:16cbm
Gross Vehicle Weight:25000kg
Loading Capacity of Collection Tank:2cbm
Cycle Time for Garbage Loading:20s
System Working Pressure:21MPa
Cycle Time for Garbage Unloading:45s
Max. Pushing Force:150kn
Compression Force:400kn
Color:Red, Withe, Green, Blue, Yellow
Export Markets:Global
Trademark:Sinotruk
Packing:Nude Packing/ RO-RO Ship or Bulk Ship
Standard:8325x2490x3500
Origin:Shandong, China
Production Capacity:150 Units Per Month
| Model | JHL5250ZYS |
| Chassis model | ZZ3257M3247C |
| Driving form | 6x4 |
| Total mass(kg) | 25000 |
| Curb weight(kg) | 14540 |
| Engine | WD615.87(290HP), Euro II emission standard Engine type: Diesel 4stroke direct injection engine, 6cylinder inline with water cooling, turbo-charging & inter cooling |
| Cab | HW76(one bed with A/C) |
| Transmission | HW15710(10 Forward, 2 Revise) |
| Front axle | HF7 (7000kg) |
| Driving axle | HC16 (16000kg x 2) |
| Steering system | ZF8098 |
| Tire | 12.00R20 (11pcs, including one spare tire) |
| Wheelbase(mm) | 3250+1350 |
| Front/rear Overhang (mm) | 1500 / 2250 |
| Approach/departure angle(°) | 19 / 14 |
| Maximum speed(km/h) | 75 |
| Number of spring leaf | 10/12 |
