Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Compactor Garbage Truck 8m3 Waste CE
Model NO.:DFWC
Type:Compactor
Certification:ISO9000, CCC, TS16949, EPA, EEC, RoHS, CE
Volume:10001-15000L
Emission Standard:Euro 2
Transmission Type:Manual
Engine Type:4 Stroke
Payload:20T
Fuel:Diesel
Drive Wheel:4×2
Brand:Dongfeng
Models:Single Bridge
Usage:Dump
Chassis:EQ1110GLJ
Condition:New
Steel Grade:Q235B Carbon Steel or Stainless Steel
Engine:190HP/210HP Cummins Engine
Top Manhole:API Standard, 500mm
Driving Type:LHD or Rhd Dongfeng Water Sprinkler Truck
No.of Sleeper:with One Sleeper or Without Sleeper
IR Conditioner:with A/C or Without A/C
Driver Seat:Air-Supporting Driving Seat
Tire:11r22.5/12r22.5
Pump Brand:Italian Brand or Demestic Brand
Export Markets:Global
Trademark:UG
Packing:Naked and Waxed Before on Board
Standard:CCC, ISO9001
Origin:Shenzhen, Guangdong, China
HS Code:8705909990
Production Capacity:1000unit/Month
| Chassis Brand | Dongfeng | |||
| Name | Dongfeng 4x2 8cbm 10cbm garbage compactor truck | |||
| Gross weight (kg) | 7300 | Garbage volume | 8-10CBM | |
| Rated loading (kg) | 2100 | Outline size(mm) | 7850×2480×3400 | |
| Curb weight (kg) | 5160 | |||
| Approach/Departure angle(°) | 20/8 | Front /rear hang(mm) | 1365/2465 | |
| Max speed(Km/h) | 90 | |||
| Function data | ||||
| Garbage capacity(m3) | 3-6 | Filled mouth along the ground clearance (mm) | 860 | |
| Filling cycle time(s) | 30 | Once unloading garbage working time (s) | 40 | |
| Filled once loaded garbage time (s) | 12 | Max crushing compression force (T) | 16 | |
| Max row unloading force (T) | 18 | Filled Lifting time (s) | 15 | |
