Color Coated galvanized Cold rolled Steel Coil

Product Description:

Product Description:

Pre-painted Galvanized Steel Coils

PPGI and PPGL

1) Standard: JIS G3312 CGCC & CGLCC, equivalent to ASTM A755M, EN10169

2) Grade: CGCC and CGLCC

3) Hardness: Both soft and full hard are available

4) Surface finish: With or without protect film covered

5) Thickness range: 0.16-1.20mm

6) Coil width: 600-1250mm, general 914mm, 1000mm, 1220mm and 1250mm.

7) Shape: Both sheet and coil are available

8) Coating: Z40 to Z275, or AZ30 to AZ150

9) Paint thickness: Top 5 um + (10-20) um polyester, Reverse 5-10 um Epoxy

10) Color: any RAL code, or according to customer's sample

11) Coil weight: 3-6 tons, or according to customer's requirements

12) Max loading in one 20ft container: 25 tons generally

13) MOQ: 25 tons for each thickness or color;

14) Delivery time: 2 weeks or one month generally.

15) Applications: Widely used for roof tiles, outer walls, ovens, explosive-proof steel, electrically
controlled cabinets, and industrial freezers in the residential and industrial buildings.
