High Quality Rock Wool Pipe by Cmax Construction and Industrial

Product Description:

1.Introduction

Fire proof external wall insulation rock wool strip is designed for improving the fire resistance of building external wall insulation system.This product is matched with the exterior insulation materials supporting up to less than Class A fire together, which is used as a fire buffer to increase the whole fire resistance of the external walls of the building. It has the properties of high compressive strength and tensile strength, low water absorption and moisture absorption, good dimensional stability and anti-aging

2.ROCK WOOL Standard Size

DIA Thickness (mm)

inch mm 25 30 40 50 60 70 80 90 100 120 150

1/2’’ 22 ● ● ●

3/4’’ 27 ● ● ● ● ● ● ●

1’’ 34 ● ● ● ● ● ● ●

1-1/4’’ 43 ● ● ● ● ● ● ● ● ●

1-1/2’’ 48 ● ● ● ● ● ● ● ● ●

2’’ 60 ● ● ● ● ● ● ● ● ●

2-1/2’’ 76 ● ● ● ● ● ● ● ● ●

3’’ 89 ● ● ● ● ● ● ● ● ●

3-1/2’’ 108 ● ● ● ● ● ● ● ● ●

4’’ 114 ● ● ● ● ● ● ● ● ● ●

5’’ 140 ● ● ● ● ● ● ● ● ● ●

6’’ 169 ● ● ● ● ● ● ● ● ● ●

8’’ 219 ● ● ● ● ● ● ● ● ●

10’’ 273 ● ● ● ● ● ● ● ● ●

12’’ 325 ● ● ● ● ● ● ● ● ●

14’’ 356 ● ● ● ● ● ● ● ●

15’’ 381 ● ● ● ● ● ● ● ●

16’’ 406 ● ● ● ● ● ● ● ●

18’’ 456 ● ● ● ● ● ● ● ●

19’’ 483 ● ● ● ● ● ●

20’’ 508 ● ● ● ● ● ●

22’’ 558 ● ● ● ● ●

24’’ 610 ● ● ● ● ●

3.Technical Parameters

Properties Specifications Standards

Density Tolerance ±15% GB/T 19686-2005

Fire Performance

Non-Combustible GB/T 5464-1999

Reaction to fire Class A1 GB/T 8624-2006

Thermal Conductivity

(W/mK, at70±5℃)

≤0.044 GB/T 10295

Fire Diameter 7(+/-1)um GB/T 5480. 4

Shot Content

(shot size＞0.25mm)

≤12%

Eccentricity of Pipe shell ≤5mm

4.Packaging, Transportation and Storage

Product is packed in plastic bag.During transportation and storage,please keep product away from

moisture and compressive deformation

 5.FAQ:

We have organized several common questions for our clients，may help you sincerely：

①How about your company？

A world class manufacturer & supplier of castings forging in carbon steel and alloy steel，is one of the large-scale professional investment casting production bases in China,consisting of both casting foundry forging and machining factory. Annually more than 8000 tons Precision casting and forging parts are exported to markets in Europe,America and Japan. OEM casting and forging service available according to customer’s requirements.

②How to guarantee the quality of the products？

We have established the international advanced quality management system，every link from raw material to final product we have strict quality test；We resolutely put an end to unqualified products flowing into the market. At the same time, we will provide necessary follow-up service assurance.
