Loading Port:Shen Zhen
Payment Terms:L/C,T/T
Min Order Qty:50 Meters m
Supply Capability:100000 Meters Per Day m/month
General Introduction
1. UV-Protected: Waterproof IP65 and IP68 types can be UV-Resistant, non-yellowing in at least 2 years.
2. Multiple Choice of LED Lumen: 7-8lm/6-7lm/5-6lm/4-5lm optional.
3. Good Color Consistency: use LEDs in fixed color bin for each model.
4. Specifications can be customized.
5. 2 Years Warranty; CE&RoHS Compliant.
6. Maintenance-free, Easy-installation with 3M Tape on the back.
7. Connectors, Clips, Power Supply, Controllers available
Specifications
| LED QTY/meter: | 60pcs |
| IP Rating: | IP20/IP65/IP66/IP67/IP68 Optional |
| Working Volgate: | DC12V/DC24V Optional |
| Wattage/meter: | max.14.4W |
| Current/meter: | 0.6A for 12V type/0.3A for 24V type |
| Emitting Color: | 3000-3500K/4000-4500K/5500-6500K/11000-13000K,R/G/B/Y Optional |
| Rendering Index: | 70-80Ra |
| Electrostatic Discharge: | 1000V |
| Operation Temperature | -20~50°C |
| Storage Temperature: | -20~80°C |
| PCB Color: | Black/White/Yellow Optional |
| PCB Width: | 8mm/10mm Optional |
| Packing: | 5 meters per reel |
led ring light Model Table
| IP Rate | Item No. | Light Color | Input Voltage | LED QTY./meter | Wattage/meter |
| IP20 | SL-F5050NWP-60WW | Warm White(3000-3500K) | 12V | 60pcs | 14.4W |
| SL-F5050NWP-60NW | Neutral White(4000-4500K) | ||||
| SL-F5050NWP-60PW | Pure White(5500-6500K) | ||||
| SL-F5050NWP-60CW | Cold White(11000-13000K) | ||||
| SL-F5050NWP-60R | Red(625nm-630nm) | ||||
| SL-F5050NWP-60Y | Yellow(580nm-585nm) | ||||
| SL-F5050NWP-60B | Blue(465nm-470nm) | ||||
| SL-F5050NWP-60G | Green(520nm-525nm) | ||||
| IP65 | SL-F5050WP5-60XX12 | XX stand for light color | 12V | 60pcs | 14.4W |
| (Not UV-Resistant) | (Refer to the above IP20 type) | ||||
| IP65 | SL-F5050WP5P-60XX | XX stand for light color | 12V | 60pcs | 14.4W |
| (UV-Resistant) | (Refer to the above IP20 type) | ||||
| IP66 | SL-F5050WP6-60XX12 | XX stand for light color | 12V | 60pcs | 14.4W |
| (Refer to the above IP20 type) | |||||
| IP68 | SL-F5050WP8-60XX | XX stand for light color | 12V | 60pcs | 14.4W |
| (Not UV-Resistant) | (Refer to the above IP20 type) | ||||
| IP68 | SL-F5050WP8P-60XX | XX stand for light color | 12V | 60pcs | 14.4W |
| (UV-Resistant) | (Refer to the above IP20 type) |
Applications
1. Cove Lighting,Cabinet Lighting
2. Back lighting or edge lighting for light box or sign box.
3. DIY lighting for indoor use
4. Path or contour marking
5. Decorative lighting for festivals, events, shows, exhibitions.
6. Stairway and Walkway lighting.
7. Emergency&Security lighting.
Quality Control
1.Standard anti-static and dust-free workshops;
2.Well-trained employees and advanced operating machines;
3.Finished products will be detected by detecting equipment;
4.Every product will be tested for 48 hrs,defect rate is 0.2-0.5 percent;
5.All series with top quality can meet CE,UL,FCC,RoHS and EMC demands
Trade Terms
1.Sample lead time: 1-3days
2. Production lead time: For 100~500PCS 1- 7days; 500~1000PCS 3-14days
3.Shipping freight are delivered under your requests
4.Shipping port: Shenzhen, mainland China
5.Discounts are offered based on order quantities
6.Min Order Quantity: 100PCS-200PCS (accepted sample: 1-10PCS)
7.Logo: According to your requirement
8.Packaging: 1PC /gift box/white mail order box
Delivery:
Shipping Service | Estimated Delivery Time |
DHL | 2-8 business days |
FedEx | 3-8 business days |
TNT | 2-10 business days |
UPS | 1-7 business days |
EMS | 6-14 business days |
ePacket | 7-12 business days |
China Post Air Mail | 7-15 business days |
China Post SAL | 14-30 business days |
By Air | 3-10 business days |
By Sea | 30-40 business days |
Service
1.Your inquiry related to our products or prices will be replied in 24hours.
2.Well-trained and experienced staffs will answer all your enquires in fluent English.
3.OEM & ODM, any your costomized lighings we can help you to design and put into product.
4.Distributers are offered for your unique design and some our current models.
5.Protection of your sales area ,ideas of design and all your private information.
About us
Our company is a market leading innovator and professional manufacturer in the field of high power LED, who represents the best quality lighting fixtures from its headquarter in Shenzhen, China.
We carry a full line of indoor and outdoor lighting fixtures including LED Street Light, LED Down Light, LED Strip Light, LED Corn Light, etc.Our products are designed to be reliable, functional, practical, efficient, user friendly to the installer and end-user, moderately priced and safe.
