Loading Port:China Main Port
Payment Terms:TT or LC
Min Order Qty:25 m.t.
Supply Capability:80000-100000MTS/YEAR m.t./month
Specification of China Flat Bar
Commodity: China Flat Bar
Standard: GB;JIS;ASTM
Material: Q235;Q345;A36;SS400;
Brand name: FLATSPACE
Origin place: China
Thickness: 3mm-30mm
Width:20mm-200mm
Length: Max 12m
Certification: SGS/BV
Chemical composition of Q235
|
Alloy No |
Grade |
Element(%) | ||||
|
C
|
Mn
|
S
|
P
|
Si
| ||
|
Q235
|
B
|
0.12—0.20 |
0.3—0.7 |
≤0.045 |
≤0.045
|
≤0.3
|
Physical properties of Q235
|
Alloy No |
Grade |
Yielding strength point(Mpa) |
Tensile strength (Mpa) |
Elongation after fracture(%) | ||||||
|
Thickness (mm) |
Thickness (mm) | |||||||||
|
≤16 |
＞16--40 |
＞40--60 |
＞60--100 |
|
≤16 |
＞16--40 |
＞40--60 |
＞60--100 | ||
|
≥ |
≥ | |||||||||
|
Q235 |
B |
235 |
225 |
215 |
205 |
375--500 |
26 |
25 |
24 |
23 |
Usage/Applications of China Flat Bar
Widely used for construction, Machinery manufacturing, Iron tower steel structure, Shipbuilding; Steel grating, Staircase, Bridge, Viaduct, Railway spare parts, Boilers making etc.
Production Flow of China Flat Bar
The steel flat bar is made through three processes:
1.Feeding the material: Feeding the row material (the steel plate) to Slitting Line.
2.Slitting:The steel plate would be slitted into expected width by lengthways cutter.
3. Leveled and cutting: The plat bar would be ground into level by the grinder and then cut into required length.
Packaging & Delivery of China Flat Bar
Packaging Details: The Steel Flat Bars are packed in bundles and loaded in 20 feet/40 feet container, or shipped by bulk cargo ,also we can do as customer's requirements.
Delivery Details:30~45 days upon the receipt of buyer payment by T.T. or L/C
