Loading Port:Tianjin
Payment Terms:TT or LC
Min Order Qty:100 unit
Supply Capability:4000 unit/month
| Standard or Nonstandard: | Standard | Structure: | Check | Pressure: | Medium Pressure |
| Power: | Hydraulic | Material: | Casting | Temperature of Media: | Medium Temperature |
| Media: | Water | Port Size: | DN40-300 | Place of Origin: | China (Mainland) |
| Model Number: | CMAX-BCV05 | Brand Name: | CMAX | ball check valve: | cast iron ball check valve |
| DIN3202 ball check valve: | DI ball check valve |
| Packaging Details: | wooden box for exporting |
| Delivery Detail: | 30--60 days |
DIN 3202 F6 ductile iron ball check valve
high quanlity DIN ball check valve with lower price, body material : ductile iron and DIN 3202 F6 ductile iron ball check valve
ball check valves
1.size:PN16,DN40-DN400
2.certificate:ISO9001 CE
3.gurantee:12months
4.packing:plywoodcases
available medium:x-water T-water,steam,W-petroleum products
working temperature:X-≤50 T-≤200oC W-≤100oC.
flange dimensions:DIN2533
face to face dimensions:DIN3202F6
1.Technical Date:
Size: DN40-DN600
Nominal Pressure: PN10/PN16
Operation Temperature: -10°C~425°C
Suitable Medium: Water.
2.Feature
1) the valve is suitable for use in medium for water, oil, steam piping, as to prevent the medium counter-current, H44H type can also be used in the corrosive gas and liquid medium in pipeline;
2) the valve flange connection, connection size according to the provisions of the JB78-59 structure length according to the provisions of the JB96-75;
3) the valves on the pressure of the inlet medium effect, the valve opens, media through; When the inlet pressure drop or disappear, the disc due to gravity and the role of the outlet pressure of medium, since the valve closed, preventing medium counter-current;
4) product model: H44T - 10. Technical parameters Nominal pressure PN (MPa)1.0 working temperature (℃) < 200
Performance description: applicable to medium for water, oil, steam piping, as to prevent the medium counter-current, H44H type can also be used in the corrosive gas and liquid medium in pipeline.
