Product Description
Four Post Car Lift
Hydraulic cylinder located in the fixed platform and is thus perfectly protected.
High resistance galvanized and pre-stretched lifting cable.
Adjustable parking ratchet rails ensure the platforms and cross members horizontal within 4 wheel alignment tolerances.
Automatic spring loaded in the event of cable breakage and ensures complete stability during parking.
Electric remote-controller.
Self large diameter pulleys.
2pcs Hydraulic two-level 2ton scissor jack. (OPTION)
Detachable align platforms. (OPTION)
With CE certificate
Parameter:
Item No. | CMCL4.0 |
Lifting capacity | 4000kg |
Lifting height | 1760mm |
Minimum height | 181mm |
Overall height | 2140mm |
Overall length | 5210mm |
Overall Width | 3220mm |
Runway Width | 530mm |
Lifting time | ≤60s |
Lowering time | >30s |
Motor | 220V/380V 50Hz/60Hz 1Ph/3Ph |
Gross weight: | 1050Kg |
