General Information Of Galvalume Steel Coil AZ150
With Cold Rolled Steel as base metal,with the aluzinc coated, finally the plate steel is called galvalume steel. Galvalume steel is good capable of decoration, molding, corrosion resistance. It generally displays superior workability, durability and weather resistance.
|
Thickness 0.25-4.0mm (BMT) |
|
Aluzinc Coating 50-150g/m2 |
|
Width 900-1250mm |
|
Internal Diameter 508mm or 610mm |
|
Coil Weight 4-8MT |
|
Quality Commercial and structural quality |
|
Surface Treatment Oiled or Dry, Chromated, Anti-finger,Non-skinpass,/ Skinpass |
|
Standard JIS G 3321, ASTM A792M, EN 10215 |
|
Base Steel Grade SGCC,SGCD,DX51D+Z,DX52D+Z;S200GD,S220GD, S280GD,S350GD,CS,FS,SS |
Chemical Composition Of Galvalume Steel Coil AZ150
|
C |
Si |
Mn |
P |
S |
|
0.04-0.06% |
0.01-0.03% |
0.18-0.22% |
0.014-0.016% |
0.006%-0.009% |
Technical Data Of Galvalume Steel Coil AZ150
|
Yield Strength |
(Mpa) 280-320 |
|
Tensile Strength |
(Mpa) 340-390 |
|
Elongation |
20%-30% |
|
Out- of-Square |
Not exceed 1% Flatness |
|
Bow |
15mm max |
|
Edge Wave |
9mm max |
|
Centre Buckle |
8mm max |
|
Bending At 180 Degree |
No crack, purling and fraction |
Application Of Galvalume Steel Coil AZ150
Aluzinc Steel can be widely used in transportation, light industry, civil usage and farming. It is also the perfect building material in construction for making roofing tile, steel profiles for wall partition, T-bar, studs, fireproof door, air conditioning duct and home appliances.
Packaging & Delivery Of Galvalume Steel Coil AZ150
Full wrapped with anti-damped paper inside, iron sheet wrapped outside, and bundled with iron strips.
