Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Model NO.:HQM388
Type:Large Loader
Usage:Universal Type
Scraper Type:Front End Shovel,Backhoe
Transmission:Hydraulic Transmission
Walking Mode:Wheeled
Load and Unload Method:Front Discharge
Engine Power:<74kw
Certification:CE, ISO9001: 2000, SGS,Rops&Fops
Condition:New
Color:According to The Customers Requirments
Connection:Overall Connection
Engine:Cummins or Yto
Operating Weight:7600kg
Warranty:1 Year
Export Markets:Global
Trademark:Haiqin
Packing:1 Unit in One Hq40 Container
Standard:CE, ISO, SGS, ROPS&FOPS
Origin:Shandong, China
HS Code:84295100
Production Capacity:8000 Units / Year
Backhoe wheel loader WZ30-25 specifications:
Overall Dimension
1, Length X Width X Height 5900X 2300 X 3769(mm)
2, Cab roof height:" 2900(mm)
2, Wheel base: 2250(mm)
3, Track :1640(mm)
4, Min. Ground clearance :300(mm)
Main Technical Specification:
1, system pressure
Load hydraulic system :18Mpa
Dig hydraulic system: 20Mpa
Steering hydraulic system :12Mpa
2, system flow :120L/min
3, four-wheel drive, whole hydraulic system
4, total operating weight :7600kg
5, maximum speed 22Km/h
6, maximum gradient capacity 30°
1, loading bucket capacity :1m3
2, rated loading :1800KG
3, maximum articulated height of bucket: 3400(mm)
4, bucket discharge height: 2795(mm)
5, bucket discharge distance :1048(mm)
6, loading lift capacity: 25KN
7, bucket hydraulic translation function: yes
8, bucket lift time: 6.8s
9, bucket lower time: 2.5s
10, bucket discharge time :1.2s
11, maximum tractive force :39KN
12, maximum breakout force: 38KN
1, backacter bucket capacity :0.3m3
2, backacter discharge height :3878(mm)
3, maximum digging depth: 4080(mm)
4, maximum digging radius: 5688(mm)
5, bucket slewing angle 190°
6, bucket digging capacity 46KN
7, bucket stick digging capacity 31KN
Diesel engine
1, model YTO YTR4108G60-1 LRC4M-3G93 or Cummins engine.
2, type inline, directinjection, four-stroke, liquid cooled
3, rated power 75HP 90HP
Rated speed 2400r/min 2400 r/min
4, cylinder. Internal diameter 4_105 4_110
5, maximum torque 285NM 310NM
6, minimum fuel consumption 239g/kw. H 245g/kw. H
7, displacement 4.33L 4.5L
Transmission system
1, model of hydraulic pump fixed shaft power shift transmission
2, gear shift 2forward shift 2 reverse shift
3, torque YJ-280
4, drive pump CDXaf3016-IL
5, flow 16ml/r
6, work pump CBGj2063
7, flow 63ml/r
Steering system
1, type articulated hydraulic steering
2, model of steering control valve BZZ5-250
3, model of turning control valve YSF25S-00
4, steering angle 36± 1° Left or right 36± 1°
5, minimum turning radius 5018(mm)
Wheel
1, tire size 16/17-20
2, front wheel pressure 0.22Mpa
3, rear wheel pressure 0.20Mpa
4, service braking air over hydraulic disc on 4 wheels
5, parking brake manual parking brake
| Operating weight | 7640Kg | Final Reducer | Single stage final reducer | |
| Transportation dimension L*W*H | 5910x2268x3760mm | Rated Loader of Axle | 7.5t | |
| Wheel base | 2250mm | Transmission system | ||
| Torque Convertor | ||||
| Min. ground clearance | 300mm | Model | YJ280 | |
| Loading bucket capacity | 1.0m 3 | Type | Single-stage, Three elements | |
| Breakout force | 38KN | Max. efficiency | 84.4% | |
| Loading lifting capacity | 2500kg | Inlet pressure | 0.4Mpa---0.55Mpa | |
| Bucket dumping height | 2742mm | Outlet pressure | 1.2Mpa_1.5Mpa | |
| Bucket dumping distance | 1062mm | Cooling method | Oil-cooling Pressure Circulation | |
| Digging depth | 52mm | Gearbox | ||
| Backhoe capacity | 0.3m 3 | Type | Fixed shaft power transmission | |
| Max.digging depth | 4082mm | Oil pressure of clutch | 1373Kpa --- 1569Kpa | |
| Swing Angle of Excavator Grab | 190 ° | Gears | Two gears forward, two gears backward | |
| Max. puling force | 39KN | Max. Speed | 22Km/h | |
| Engine | Tyre | |||
| Model | YTR4108G60-1 | Model | 16/70---20 | |
| Type | Vertical, direct inject, 4-stroke, combustion chamber | Pressure of front wheel | 0.22 Mpa | |
| Pressure of rear wheel | 0.22 Mpa | |||
| Cylinder-Inside diameter*stroke | 4---108*120 | Brake system | ||
| Rated power | 55KW | Service brake | Air over oil caliper brake | |
| Rated speed | 2400r./min. | External type | ||
| Min. fuel consumption | ≤ 216g/km.h | Self-regulation | ||
| Max. Torque | ≥ 261.7N.M/1800r./min. | Self-balance | ||
| Displacement | 4.4L | Emergency brake | Power asst. | |
| Manual asst. | ||||
| Steering system | ||||
| Model of steering device | BZZ5---250 | Hydraulic system | ||
| Steering angle | ± 36 ° | Hoe bucket digging power | 46.5KN | |
| Type | 5018mm | Dipper digging power | 31KN | |
| Model of tuming control valve | 12Mpa | Bucket lifting time | 5.4S | |
| Axle | Bucket lowering time | 3.1S | ||
| Main transmission type | Double reduction | Bucket discharge time | 2.0S | |
