Loading Port:Tianjin
Payment Terms:TT OR LC
Min Order Qty:25 m.t.
Supply Capability:6000 m.t./month
ASTM -A36 Hot Rolled H-Section Steel Column
Quick Details
Place of Origin: | China (Mainland) | Grade: | ASTM -A36 | Technique: | Hot Rolled |
Thickness: | 4mm - 16mm | Application: | decoration,kitchen,building,medical treatment,transport,chemical indus | Length: | 12 m |
Standard: | GB JIS | Flange Width: | 100--500mm | Flange Thickness: | 8--70mm |
Web Width: | 100--1000mm | Web Thickness: | 5--40mm | ||
Model Number: | H section steel ASTM -A36 | Exported Area | USA,Europe,Asia,Middle East,Africa,South America |
Application
decoration,kitchen,building,medical treatment,transport,chemical indus
Specifications
We are professional supplier and exporter of H beam.
Size:100*50*5*7mm - 700*300*13*24mm
Specification
Model Table in mm
100×50×5×7 | 200×204×12×12 | 338×351×13×13 | 482×300×11×15 |
100×100×6×8 | 244×175×7×11 | 340×250×9×14 | 488×300×11×18 |
125×60×6×8 | 244×252×11×11 | 350×175×7×11 | 496×199×9×14 |
125×125×6.5×9 | 248×124×5×8 | 350×350×12×19 | 500×200×10×16 |
148×100×6×9 | 250×125×6×9 | 360×250×12×19 | 582×300×12×17 |
150×75×5×7 | 250×250×9×14 | 360×350×12×19 | 588×300×12×20 |
150×100×6×9 | 250×255×14×14 | 390×300×10×16 | 594×302×12×20 |
150×150×7×10 | 294×200×8×12 | 396×199×7×11 | 600×200×11×17 |
175×90×5×8 | 294×302×12×12 | 400×200×8×13 | 600×300×12×20 |
175×175×7.5×11 | 298×201×9×14 | 400×400×13×21 | 700×300×13×24 |
194×150×6×9 | 300×150×6.5×9 | 414×405×18×28 | 800×300×14×26 |
200×100×5.5×8 | 300×200×8×12 | 440×300×11×18 | 900×500×16×28 |
200×150×6×9 | 300×300×10×15 | 450×200×9×14 | |
200×200×8×12 | 300×305×15×15 | 450×300×11×18 |
