Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 PCS
Supply Capability:1500 PCS/month
Model NO.:ZY210SD
Type:Crawler Excavator
Usage:Mining Excavator
Bucket:Dragline
Transmission:Hydraulic Transmission
Drive Type:Electric Drive
Bucket Capacity:1.0~1.5m³
Size:Medium-Sized
Certification:CE, ISO9001: 2000
Condition:New
Product:Rongsheng Amphibious Excavator Zy210SD 30ton
Export Markets:Global
Trademark:RONGSHENG
Packing:N/P
Standard:CE
Origin:China
Production Capacity:30sets/ Month
Imported Isuzu engine
Original imported hydraulic components
Luxurious cabin with air conditioner
| Specification | ||
|---|---|---|
| Operating weight | 30000kg | |
| Standard bucket capacity | 0.8m 3 | |
| Track shoe width | 1508mm | |
| Arm length | 2912mm | |
| Engine | ||
| Model | 6BG1TRP-03 | |
| Type | Turbo-charged with inter-cooled | |
| Power | 114kw/2100rpm | |
| Max. torque | 629N. m at1600rpm | |
| No. of cylinders | ||
| Displacement | 36.49L | |
| Hydraulic system | ||
| Main pump | Type | Variable displacement axial piston pumps |
| Max. displacement | 2× 107L/min | |
| Pilot pump | Type | Gear pump |
| Max. flow | 20LL/min | |
| Working pressure | 32Mpa | |
| Hydraulic motor | Slew | Fixed displacement axial piston motor |
| Travel | Variable displacement axial piston motor | |
| Performance | ||
| slew speed | 11rpm | |
| Min. back slew radius | 2801mm | |
| Max. travel speed high/low | 3.29/2.17km/h | |
| Gradeability | 35° | |
| Tractive effort | 382.4kN | |
| Max. digging force of bucket | 122.85kN | |
| Max. digging force of arm | 97.6kN | |
| Ground pressure | 0.48kg/cm 2 | |
| Tank capacity | ||
| Fuel tank capacity | 376L | |
| Hydraulic tank capacity | 219L | |
