Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:5 m.t.
Supply Capability:30000 m.t./month
Packaging & Delivery
Packaging Details: | Standard export packing or following customer's demand |
Delivery Detail: | Within 25-30 days or according to the order quantity |
Specifications
Grade
| 1000 Series: 1050 1060 1070 1100 1200 1235 etc. 3000 Series: 3003 3004 3005 3104 3105 3A21 etc. 5000 Series: 5005 5052 5083 5086 5154 5182 5251 5754 etc. 6000 Series: 6061 6063 6082 6A02 etc. 8000 Series: 8006 8011 8079 etc. |
Thickness | 0.05~10mm |
Width | <1600mm< span=""> |
Color | Metallic, Solid, RAL or by customer requirements |
Coating paint: | PVDF(Polyvinylidene Fluoride), PE(Polyester ) |
Coating thickness | as per customer’s request |
Gloss | 10-90%(EN ISO-2813:1994) |
Total coating thick | Polyester18~27micron(EN ISO-2360:1995) PVDF27 ~35micron(EN ISO-2360:1995) |
Coating hardness | 2H |
Protective film | PVC film, Colorless transparent or White-black |
Adhesion | 5B (EN ISO-2409:1994) |
Impact resistance | No cracking and peeling (A.S.T.M D2794-1993) |
Flexibility (T-bend) | 0T- 2T |
Temper | H16, H18, H24, H26, H26 |
Certification | ISO9001:2000, CE, SGS |
Coil's standard diameter | 1100mm |
Inner Diameter | 405mm/505mm |
Coil's standard weight | 2000kgs |
Payment | L/C ,T/T |
Color coated Aluminum coil means coloring is processed onto the surface of aluminum coil by coating PE or PVDF paints. It is widely applied to many kinds of fields, like Aluminum composite panels, solid aluminum single panel, aluminum honeycomb panel, aluminum ceiling, aluminum roofing, pop-top cans, home appliance, electronic products etc.. By taking advantages of many features, such as stable property, anti-corrosion, 30years guarantee after special process, the lowest density in metals, the color coated aluminum become one of the most popular new materials.
| Aluminum Alloy Series | A1100, A3003, A3004, A3105, A5052, A8011 etc... |
| Coatings | PE or PVDF normally |
| Coating thickness | PE: no less than 18micron; PVDF: no less than 25micron; |
| Aluminum Thickness | 0.2mm ~ 1.5mm normally, could be custom-made |
| Width | For Coil:15mm ~ 1500mm normally; As per order For Sheet:500mm ~ 2000mm;As per order |
| Coil Interior Diameter | 150mm,405mm,505mm,508mm,510mm normally |
| Gloss | 10~90%, (EN ISO-2813:1994) |
| Other features | Please consult with us |
Coating Hardness (pencil resistance) | more than 2H |
| Impact Resistance | No peeling or cracking(50 kg/cm,ASTMD-2794:1993) |
Flexibility (T-bend) | 2T |
| MEK resistance | More than 100 |
| Colors | RAL colors |
| Surface | embossed, mill finish, coated |
FAQ
1. How can I get some samples?
We are honored to offer you samples. New clients are expected to pay for the courier cost. The samples are free for you.
2 Do you have any certificates?
Our products passed inspection of SGS, FDA, and CE Quality is priority! Every worker keeps the QC from the very beginning to the very end, Quality control department especially responsible for quality checking in each process.
3 Can your factory print or emboss my logo on the goods?
Yes, we can print or emboss the logo on the goods or their packing box.
4 What information should I let you know if I want to get a quotation?
1) The specification of products (length x width x thickness);
2) The temper and alloy.
3) The final product you will use to be made
4 It will be better if you can show us the pictures or design sketch. Samples will be best for clarifying. If not, we will recommend relevant products with details for reference.We usually produce goods based on customers
Samples or based on customers’ picture, logo, sizes etc.
Our Services
1. Reasonable production arrangement to make delivery very fast;
2. We are able to provide leading tolerances, metallurgical assistance, quick and reliable delivery, samples for new products, etc.
3. We have the strong capability to meet your particular requirement for the products.
4.To guarantee the quality of the products we can meet most of the standards all over the world.
Photos
