Loading Port:Shanghai
Payment Terms:TT OR LC
Min Order Qty:1 m.t.
Supply Capability:2000 m.t./month
Product Description:
The heat treatable alloys of 2000, 6000 and 7000 are such that when subjected to thermal temperatures, they again pronounced strengthening. Hence, tempers are indicated by "T". These alloys are also inventoried in clad form to increase corrosion resistance. All of the aluminum alloys are available in the annealed condition or commonly referred to as "O".
Aerospace - 2024, 6013, 6061, 7075
Construction - 3003, 5052, 6061
Electrical and Chemical Applications - 1100
General Machining Applications - 3003, 5052
Thickness from 0.18mm to more than 200mm are available for your needs. Aluminum can process to your special requirements and support traceability with complete Mill Test Certificate(MTC) and the essential industry specifications. More details about Aluminum sheet coil for Beverage Cans, Food Cans & Closures as following
Aluminum coil for aluminum composite panel
Always present in the development of aluminum coil for the Beverage Cans Making Industry, LingFeng offers Aluminum Coils for Beverage Can Body Stock, Coated End Stock and Bare or Coated Tab Stock. Lingfeng rolling facilities include: Modern equipment that guarantees high efficiency in the can makers lines and possible light-weight. A state-of-the-art lacquering line suitable for the coating of easy open end and tabe. PVC-free, BADGE-free and Solvent-free (free-based) lacquering systems are applied.
Being able to produce according to detailed customer requirements, Lingfeng can provide tailor-made solutions.
Aluminum sheet coil for Food Cans
New lacquerng line is suitable for the coating of bodies, lids and tabs of rectangular or round Food Cans for aggressive food or fruit-juice products. BADGE-free and Solvent-free (water-based) lacquering systems are applied. The material can also be supplied degreased, chromium phosphated and DOS treated.
Aluminum sheet coil for Closures
Committed to continuous development and full customer satisfaction, Lingfeng offers Pre-treated and Pre-coated Coils or Straight-cut Sheets for the production of Pilfer-proof Caps. Lingfeng provides high quality non-earing material, suitable for both one and two step Drawn Caps. Rolling experience and new lacquering facilities ensure excellent service in terms of products range and J. I. T deliveries providing Closures in three different aluminum alloys and two alternative finishes, bare or coated. Lingfeng material is used for the production of Pilfer Caps for carbonated and non-carbonated beverages, alcoholic or non-alcoholic drinks and as closures for pharmaceutical products.
Aluminium Coil PPGL Specification:
Quality Certification
According to EN and GB/T standards or as per agreed customer specifications.
Aluminum Coil for Beverage Cans, Food Cans and Closures Specifications
| Production Range (mm) | |||||
| Aluminum Sheets/Coils for Food Cans | Aluminum Sheets/Coils for Food Cans | ||||
| Thickness | Width | Thickness | Width | Length | |
| Body | 0.250 min. | 2300 max. | 0.18-0.25 | 500-1020 | 1045 max. |
| End | 0.222 min. | 2300 max. | 0.20-0.30 | 100-1020 | 1045 max. |
| Tab | 0.235 min. | 45 min. | 45 min | 29 min. | Coils only |
| Production Range (mm) | ||||
| Beverage Cans- Dimension | Food Cans-Coil Dimensions | |||
| Inside Diameter | Outside Diameter | Inside Diameter | Outside Diameter | |
| Body | 400 or 500 | 1850 max. | 400 or 500 | 1800 max. |
| End | 400 or 500 | 1850 max. | 300 or 400 or 500 | 1800 max. |
| Tab | 400 | 1850 max. | 300 or 500 | 1800 max. |
| Closures-Dimension Range | |
| Thickness | 0.20-0.3 |
| Width | 500-1020 |
| Length(Sheet) | 1045 max. |
| Inside Diameter | 300 or 400 or 500 on carton core |
| Outside Diameter | 1800 max |
| Finishes-Treatment | |||
| Beverage | Food | Closures | |
| Body: | Pre-lubricated: According to customer requirement. | Degreased, Chromium phosphate converted and DOS treated. | Pre-treated: Degreased, Chromium phosphate converted and if requested DOS treated. |
| End: | Pre-coated & Pre-maxed: According to customer requirements. | Pre-treated: Degreased, Chromium phosphate converted and DOS treated. Coated: Pre-waxed and lacquered on public or product side of the can, or both. | Coated: Lacquered on either or both sides. |
| Tab: | Coated: Clear or coloured expoxy, or bare: degreased and DOS re-oiled | Coated: Clear or coloured coated or bare: degreased and DOS re-oiled | |
FAQ of Aluminium Coil for ACP (Aluminum Composite Panel):
1.Superior quality of raw material.
2.Reasonable and stable chemical composition.
3.Accurate tolerance.
4.Goode mechanical property.
5.We have the certificate of ISO9001.
